auto body mig welder denting puller ,Multi functional welding machines

Product Overview

Description

auto body mig welder-dent puller ,Multi-functional welding machines



Technical Parameters



Model:SG-7500/315
Input voltage:AC2PH380V 50/60Hz
Rated power:18.8KVA
Input current:15.2-85A
Output current:270A/27.5V
Welding machine output current:270A/35%
Repair output current:7500A
Floating Voltage:5-38V
Insulation grade:f
Welding diameter:Φ0.8-1.0mm
Gear:7



Standard Accessories







Functions And Features



Patch corrugated line equipped with a variety of specifications, can be used for repair welding of different damage degree and the parts, but for car bumper and other plastic parts repair head and raze rubber cutting operations such as automobile sheet metal welding repair machines: mobile and convenient, easy operation, large output power, with a touch welding tensile, heat, shrinkage, sheet, spot welding, stud, steel plate cutting, plate welding function.Disintegration of the correct use of the machine, do not need to vehicles, can quickly to welding to repair the car, is one of the ideal equipment for automobile repair industry.
1, Unique automatic monitoring grid voltage function, digital display welding and set parameters;
2, With functions of welding repair a key transformation;
3,Overheationg protection;
4,High precision time adjustment system;
5,Have a draw triangles for pulling of sheet metal;
6, Various welding procedures are available such as shrinking, washer welding, dent pulling spot welding, flattening, waveform wire welding, stud welding, OT washer welding, triangle washer welding etc;

 7,Airframe design has a cylinder protection plate, a cylinder can be stably fixed on the machine.
