Wood flour grinder/ timber grinder/wood grinder

Product Overview

Description

Wood flour grinder/ timber grinder/wood grinder(the highest quality)

Wood flour grinder/ timber grinder/wood grinder Brief introduction:

     This machine is mainly used for,wood, twigs , wood powder , bamboo powder , miscellaneous wood powder, cork powder ,bamboo and wood powder, bake lite powder, bamboo, tree bark ,poplar wood powder, pine, redwood,mahogany,  cleaning powder,dust cleaning powder, oak powder , Paper-making wood powder, incense wood flour , leather and other the raw material grinding/milling operations.wood powder fineness in 40-325 mesh can be arbitrary control,widely used in chemical , building materials,woodworking, medicine, health protection, breed aquatics ,foodstuff, mosquito-repellent incense ,paper-making, leather and other industries.

Wood flour grinder/ timber grinder/wood grinder Composition:

Cutter ,the knife dish , spindle, the machine body , fineness analyzer ,draught fan, powder collector , dust collector and other components Ministries

Wood flour grinder/ timber grinder/wood grinder Working principle:

Material from the feed port to feed , grinding tools, highspeed rotation after three knives, the material for compression , friction, tearing and other physical milling mode , complete the material grinding operation ,And then the powder is sent by the qualified fineness fineness analyzer , not qualified powder hopper back through the inlet port to return repeatedly ground until qualified,qualified leads from the fan to the powder , powder collector , dust to dust dust removal operation .

Wood flour grinder/ timber grinder/wood grinder Features :

1 : The machine adopts the double hollow body, circulating water cooling device can be added internally , pull off the high speed grinding heat problem ;

2: A3 steel knives, broken fire after treatment, more wear-resistant , better crushing effect ;

3: The fineness analyzer , strict control of product fineness , to ensure product quality ;

4 : fineness control devices , according to the fineness required , at any time to adjust the fineness ;

5 : The machine adopts 6MM thick chassis , after installation, you can play a good damping effect .

Wood flour grinder/ timber grinder/wood grinder Parameter:

MODEL	450	600	750	1000
Max feed size(mm)	3-5	3-5	3-5	3-5
Maximum material hardness(Morse)	Fibrous	Fibrous	Fibrous	Fibrous
Moisture content of materials	drying	drying	drying	drying
Grinding fineness()	40-325	40-325	40-325	40-325
Yield(kg/h)	30-150	60-220	80-300	100-600
Main engine rate of revolution(speed/minute)	3200	3400	3200	2200
The host power(kw)	18.5-22/2	22-30/2	37-45/2	75-90/2
The fan power(kw)	5.5/2	5.5/2	7.5/2	15/2
The weight of the machine(kg)	1450	1850	2800	5500

Wood flour grinder/ timber grinder/wood grinder Finished Products :

Wood flour grinder/ timber grinder/wood grinder equipment Exhibition:
