High pot lead acid battery grid casting machine

Product Overview

Description

High pot lead acid battery grid casting machine

I General indroduction of High pot lead acid battery grid casting machine

As a special equipment to produce the lead calcium grid of lead-acid accumulator, ZGX40D casting machine has the advantages of consumption saving, reasonable structure, convenient operation, easy maintenance, wide production scope, reliable running etc.



II Range of supply of High pot lead acid battery grid casting machine

ZGX40D Grid casting machine (High pot):

Main casting machine    1 set

Lead melting Furnace   1 set

Circulating tank         1 set

Lead feeding system     1 set

Electric control system   1 set



III Main technical parameters of High pot lead acid battery grid casting machine

1. Production efficiency: 6-17 large/ min

2. Casting range: 400 × (100-165) × (1.2-4.0) mm

3. Total power: 43kw; Actual power: 26kw

4. The application of grid alloy: lead-antimony alloy: 1.6-4.5%, Pb-Ca alloy: 0.08-0.14%,

5. Mold grid: According to grid drawings design provided by users

6. Lead-melting furnace temperature control: Temperature control adjustable: 430-550 °C, the working range of ± 10 °C.

7. Grid mold temperature control: on the mode: 150-170 °C, under the mode: 170-190 °C.

8. Lost lead tube temperature control: temperature control: 450-520 °C, heat for short-circuit heating, heating power 6KW.

9. Lead spoon temperature control: temperature control: 450-550 °C



IV Photos of  High pot lead acid battery grid casting machine



V Guarantee of High pot lead acid battery grid casting machine :within one year since the date of B/L





We, Nantong Zhenhuan Trade Co., Ltd., are specialized in machines for more than 15 years. We can provide you good quality High pot lead acid battery grid casting machine as well as good service.



Pls contact us for more service and information of High pot lead acid battery grid casting machine
