Ferrite core power loss tester
- Category: >>>
- Supplier: Sanshine (Xiamen) Industrial And Trading Co. Ltd.
Share on (60496597447):
Product Overview
Description
Product Description
Description of SS-SML01 Ferrite core power loss tester :
This SS-SML01 Ferrite core power loss tester include one set broadband power signal generator and one set W-A-V meter, the broadband power signal generator are specially researched and manufactured for the testing of the soft magnetism materials .With a wide operating frequency, high power output, high quality waveform and convenient operation, the instruments are ideal power signal source for the testing and determination of the soft magnetism materials, high frequency fluorescent lamp, high frequency nonpolar lamp. They are designed to be used for power signal source of corresponding frequency band in factories and laboratories.
The W-A-V meter adopts the principle of Voltage with Ampere of product of IEC standard. The SS-ML01 tester can measure the core loss(soft magnetic core, amorphouse magnet core etc.) in quickly, easy, exactly. But the cores can not be gap.
Specification of SS-SML01 Ferrite core power loss tester:
This SS-SML01 Ferrite core power loss tester include one set broadband power signal generator and one set W-A-V meter, the broadband power signal generator are specially researched and manufactured for the testing of the soft magnetism materials .With a wide operating frequency, high power output, high quality waveform and convenient operation, the instruments are ideal power signal source for the testing and determination of the soft magnetism materials, high frequency fluorescent lamp, high frequency nonpolar lamp. They are designed to be used for power signal source of corresponding frequency band in factories and laboratories.
The W-A-V meter adopts the principle of Voltage with Ampere of product of IEC standard. The SS-ML01 tester can measure the core loss(soft magnetic core, amorphouse magnet core etc.) in quickly, easy, exactly. But the cores can not be gap.
Specification of SS-SML01 Ferrite core power loss tester:
Broadband power signal source : | ||||||||||
power signal source model | output voltage(Vrms) | output frequency range(KHz) | non-liner distortion(full load) | Max. output power(W) | voltage display range(V) | |||||
A | 60/120/180/240<±0.5%/h | 10 ~ 500≤±0.5% | 10KHz ~ 200KHz<2% 200KHz ~ 500KHz<3% 500KHz ~ 1000KHz < 5% | 160 | 60/120/180/240 ±1.0 | |||||
B | 60/120/180/240<±0.5%/h | 10 ~ 1000≤±0.5% | 160 | 60/120/180/240 ±1.0 | ||||||
C | 120/240/360/500<±0.5%/h | 10 ~ 200≤±0.5% | 300 | 120/240/360/500 ±1.0 | ||||||
D | 15/30/45/60<±0.5%/h | 10 ~ 500≤±0.5% | 160 | 15/30/45/60 ±1.0 | ||||||
E | 120/240/360/500<±0.5%/h | 10 ~ 100≤±0.5% | 600 | 120/240/360/500 ±1.0 | ||||||
F | 200/300/400<±0.5%/h | 10 ~ 400≤±0.5% | 300 | 200/300/400 ±1.0 | ||||||
W-A-V meter : | ||||||||||
voltage measure range | voltage measure accuracy | current measure range | power measure range | power measure accuracy | frequency measure range | |||||
20V(2.0 ~ 40.0V) | ±0.5% (1KHz ~ 300KHz) ; ±0.5% (300KHz ~ 500KHz) | 50mA(5.0 ~ 100mA) | 0.1W ~ 500W | ±1.0% (1KHz ~ 300KHz) ; ±1.0% (300KHz ~ 500KHz) | 1KHz ~ 500KHz | |||||
100V(10.0 ~ 200.0V) | 250mA(25.0 ~ 250mA) | |||||||||
200V(20.0 ~ 400.0V) | 500mA(50.0 ~ 500mA) | |||||||||
Max. 600V | 2500mA(250.0 ~ 2500mA) | |||||||||
