Long standby rechargeable Portable mobile handheld bluetooth 58mm receipt thermal printer for Android ios
Product Description
| Specification | ||||||||||
| Paper | Type | Thermal | ||||||||
| Width | 57.5±0.5mm | |||||||||
| Thickness | ≤0.12mm | |||||||||
| Diameter | ≤50mm | |||||||||
| Roll diameter | ≤40mm | |||||||||
| Feed | Easy(Clameshell feed) | |||||||||
| Printing | Method | Thermal direct line | ||||||||
| Effective width | 48mm (384dot) | |||||||||
| Speed | 70mm/sec | |||||||||
| Resolution | 203DPI (8dot/mm) | |||||||||
| Command | ESC/POS/STAR | |||||||||
| Graphics | Support bitmap download and print (Max 8KB and 5pieces) | |||||||||
| ANK Character | Font A(12*24) | 1.5(W)*3.0(H)mm | ||||||||
| Font B(9*17) | 1.1(W)*2.1(H)mm | |||||||||
| Simplified/Traditional(24*24) | 3.0(W)*3.0(H)mm | |||||||||
| TPH Reliability | 50km(printing desity≤12.5) | |||||||||
| Buffer Input | 4KB | |||||||||
| Buffer NV Flash | 40KB | |||||||||
| Line spacing | 3.75mm(Can adjust line spacing by command) | |||||||||
| Extended character set | PC437/Katakana/PC850/PC860/PC863/PC865/ WestEurope/Greek/Hebrew/EastEurope/Iran/ WPC1252/PC866/PC852/PC858/IranII/Latvian/ Arabic/PT151,1251/PC737/WPC/1257/ThaiVietnam/ PC864/PC1001/(Latvian)/(PC1001)/(PT151,1251)/ (WPC1257)/(PC864)/(Vietnam)/(Thai) | |||||||||
| Bar code | 1D Bar code:UPC-A/UPC-E/JAN13(EAN13)/ JAN8(EAN8)CODE39/ITF/CODABAR/CODE93/CODE128 | |||||||||
| OS | Android,IOS,Linux,Win2000,Win2003,WinXP,Win7, Win8,Win8.1,Win10 | |||||||||
| Interface(Optional) | IOS or Serial | |||||||||
| Power Adapter | Input:AC 110V/220V 50~60Hz Output:DC 9V/2A | |||||||||
| Battery | Rechargeable Lithium polymer battery 7.4VDC/2000mA | |||||||||
| Operating environment | Temp:4~ 45℃,Humidity:10 ~ 80% | |||||||||
| Storage environment | Temp:-10 ~ 50℃,Humidity:10 ~ 90%(No Dew) | |||||||||
| Dimensions | 180*125*70mm 0.5kg Big Carton:425*400*270mm 14kgs | |||||||||
Packaging & Shipping
Company Information
FAQ
1: Why serial port printer printing messy code?
A: Ensure the baud rate setting in the PC is same as the printer baud rate.
( we can see printer baud rate from self test page)
2: Self printing test is ok,but printer does not work after driver installation.
A: Recheck the installation according to above installation wizard and see if
we selected the right port or ask service center for advice if needed.
3: Malfunction of paper feeding?
A: Use soft brush to clean the paper sensor and try again or send it to the
service center for repair.
4: Malfunction of the indicator light
A: Check the cable connecting way / adapter / power cord / switch on or off?
Or contact the service center for repair.
5: Messy code printing except Arabic numeral printing.
A: language switching incorrectly, please use our tool "IPrinter" (you can find it
on the enclosed CD) to change the language what you want print.
6: Red indicator keep flashing during the printing.
A: Usually it is due to the high temperature of the print head. If printing
stopped,please contact the service center for repair.
