ETL DLC Premium listed 6 years warranty Bronze die casting LED flood light housing
- Category: >>>
- Supplier: GI Lighting Tech Shenzhen Ltd.
Share on (60497550327):
Product Overview
Description
Specification
New design die casting LED flood light housing
Incorporating innovative elements with integrated design, Green Inova's new die casting LED flood light housing are the ultimate design tool for transforming buildings and outdoor spaces into works of art. The specification-grade luminaires provide outputs ranging from 9799.6 to 14932 lumens, equaling the performance of 250 to 450-watt metal halide fixtures but consuming 70 percent less energy.
An outstanding combination of photometric performance and design, the fixtures are constructed with a sleek, aluminum body and tempered glass front that creates a clean, contemporary look which blends beauty into any outdoor space.
Their solid state construction renders them impervious to shock, vibration, frequent switching and environmental extemes. They are rated for a long 50,000hours lifespan and are backed by Green Inova's 6-year limited warranty.
An outstanding combination of photometric performance and design, the fixtures are constructed with a sleek, aluminum body and tempered glass front that creates a clean, contemporary look which blends beauty into any outdoor space.
Their solid state construction renders them impervious to shock, vibration, frequent switching and environmental extemes. They are rated for a long 50,000hours lifespan and are backed by Green Inova's 6-year limited warranty.
Specification chart of die casting LED flood light housing:
Wattage (W)
80W
100W
120W
Output,5000K (lm)
9799.6 Im
11973.3 Im
14932 Im
Efficacy (lm/W)
122 lm/W
125.1 lm/W
129 lm/W
NEMA Distribution (H x V)
6*6; 3*3
Color Temperature (CCT)
4000K/4500K/5000K
CRI
>75
Lumen Maintenance
(L70 @ 25°C)
(L70 @ 25°C)
50000 hours
Power Factor
>0.9
Input Voltage
AC 100-277V & 347-480V
Housing
Die cast aluminum with powder coat paint
Lens
Tempered Glass
Humidity
5% - 90% RH, non condensing
Operating Temperature
-30-45ºC
Certification
ETL/cETL, DLC Premium (E.g. 4FL120L50(BWBK)2[blankP])
Environment
RoHS compliant; no mercury
Warranty
6 Years
Size info of die casting LED flood light housing:
Product Description
High Power Nichia SMD LEDs
1.Top brand high quality Nichia chips (L90>50,000hrs).
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
2.Super high light efficacy.
3.Engineered with proprietary binned LM-80-rated LEDs, which are specially rated for higher thermal performances, provide uniform color consistency.
4.To make the color more consistent, we always use the exact same bin for all the lights in a single project. We finer tune the binning.
ADC 12 Die-cast Aluminium Heat Sink
1. Die-cast aluminum gasketed enclosure.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.
2. Protective powder coating for lasting appearance.
3. All-in-one heatsink with perfect structure maximum heat dissipation.
Great Lighting distribution
1. Two view Angles NEMA 6HX6V & NEMA 3HX3V optional.
2. To Visor help to focus on the lighting.
2. To Visor help to focus on the lighting.
Installation Options
Four Mounting options for die casting LED flood light housing: Slip fitter mount, Trunnion mount, Straight arm pole mount, 1/2' NPT connector.
Applications
NEMA 6HX6V & NEMA 3HX3V optical for die casting LED flood light housing. These two distributions to suit an array of applications including accent and facade, wall washing, flags and signage, statues, monuments, pedestrian pathways and parking lot displays.
Certifications
Qaulity Control
IQC
1.Most stringent raw material selection.
2.100% inspection of incoming raw materials.
2.100% inspection of incoming raw materials.
IPQC
1. Testing all PCB after soldering with electricity.
2. Integrating sphere testing.
3. Waterproof testing.
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
2. Integrating sphere testing.
3. Waterproof testing.
4. Cooling effect testing.
5. 100% 48 hours aging testing(72 hours for high voltage products).
FQC
1. 100% appearance checking
2. 100% label checking
3. 100% function checking
2. 100% label checking
3. 100% function checking
Company Information
Green Inova is an innovative, energetic and vibrant company, which was founded in year 2007, has been a leader in manufacturing and marketing of LED lightings. Our expertise is manufacturing LED lighting products including LED retrofit kits, LED wall packs, LED canopy lights, LED Shoebox, LED IP65 high bays, LED Flood lights, New LED PL G24 lamps and bulbs,LED Post Top Retrofit kits & LED Billboard Retrofit kits, LED Low Priofile LED Canopy, LED Barn Light etc.
98% of our products are qualified with UL, cULs, ETL, cETL, Energy Star, DLC(e.g.:4BL45L50X1P), CE, ROHS, SAA certificates.They are also with different tests such LM79, LM80, IES files etc. We are committed to providing our customers with high-tech LED lightings with excellent quality and at affordable prices.
Green Inova Services
1.Customize services are availabel when needed. OEM/ODM availabel.
2.More than 8 years experience R&D and sales engineers would offer best lighting solution for projects.
3.Best after services:Time tracking of customers' usage, collect information to improve,fast action of dealing with problems in 48 hours.
4.Quick action of technical support and maintenance.
2.More than 8 years experience R&D and sales engineers would offer best lighting solution for projects.
3.Best after services:Time tracking of customers' usage, collect information to improve,fast action of dealing with problems in 48 hours.
4.Quick action of technical support and maintenance.
