TE Connectivity /AMP 1563125 1 in stock

Product Overview

Description

Product Type Features

• Connector Style  Housing for male terminals


• Sealed  No


• Hybrid Connector  Yes


• Primary Locking Feature  On the terminal


• Connector System  Wire-to-Wire


• Row-to-Row Spacing 4.24 mm [ .167 in ]


• Strain Relief  No

Configuration Features

• Number of Positions  10


• Number of Rows  3

Electrical Characteristics

• Nominal Voltage Architecture (V) 12


• Operating Voltage (VDC) 14

Body Features

• Cable Exit Angle  180°


• Body Material  PBT GF


• Color  Black

Contact Features

• Mating Tab Width (mm) 1.2, 2.8


• Mating Tab Width (in) .047, .11

Mechanical Attachment

• Terminal Position Assurance  Yes


• Mounting Feature  Yes


• Polarized  No

Housing Features

• Pitch (mm) 2.54, 5.2


• Pitch (in) .1, .205

Dimensions

• Width 42.15 mm [ 1.659 in ]


• Height 16.2 mm [ .638 in ]


• Length 18.85 mm [ .742 in ]

Usage Conditions

• Operating Temperature (Max) (°C) 70, 75, 80, 85, 90, 100, 105, 110, 120


• Operating Temperature (Max) (°F) 158, 167, 176, 185, 194, 212, 221, 230, 248


• Operating Temperature Range -20 – 120 °C [ -4 – 248 °F ]

Industry Standards

• Degree of Protection  Other


• UL Flammability Rating  None

Packaging Features

• Packaging Method  Box/Carton


• Packaging Quantity  1100
