Carbon Steel Welding Road E6013 e7016 1/16 3mm 1.5mm Introduction
1. Model No.: Welding Rod AWS E6013(J421, J38.12)
2. Available size: 2.5x300mm, 2.5x350mm, 3.2x350mm, 4.0x400mm, 5.0x400mm
3. Packing: 5kgs/box, 20kgs/carton, 1000kgs/pallet, we could do according to the customers ‘request.
4. Delivery time: Within 20 days after confirmation
5. Application: The E6013 welding rods are widely used on both AC and DC in all position and suitable for welding sheet metal structure made of low-carbon steel, such as ships, vehicles, building, and general machinery.
Detaild Specification for Carbon Steel Welding Rod E6013 e7016 (J421, J38.12)
Chemical Compossition of Deposited Metal (%)
| C | Mn | Si | S | P |
Guaranteed value | ≤0.12 | 0.3~0.6 | ≤0.35 | ≤0.035 | ≤0.040 |
Typical value | 0.07 | 0.4 | 0.25 | 0.019 | 0.025 |
Sizes, Length & Recommended Current (AC/DC)
Diameter (mm) | φ2.0 | φ2.5 | φ3.2 | φ4.0 | φ5.0 |
Length (mm) | 300 | 300 | 350 | 400 | 400 |
Current (A) | 40~70 | 50~90 | 90~130 | 130~210 | 170~230 |
Mechanical Properties of Deposited Metal
| Rm (Mpa) | ReL(Mpa) | A(%) | KV2(J) | KV2(J) |
Guaranteed value | σb≥420 | σs ≥ 330 | δ5 ≥ 17 | (normal temperature) | -(0°C) |
Typical value | 460~540 | ≥ 340 | 18~26 | 50-80 | ≥ 47 |






Shandong Huaxiang Import and Export Co., Ltd
It is an enterprise which specialized in stainless steel products and seamless steel pipe.honest and trustworthiness ,super quality and competitive price are the objective of our business.we have high-speed service ,good communication and interpersonal skills.and formed a complete set of system for export.we have customers all over the world, like Russian ,Singapore, Canada, Australia.
WeChat and whatsapp:86-13188756906
Email:sdhx2(@)sdhxjgg.com
we are warmly welcome you to contact us!
