Smart home Wifi Smart phone wall Glass Screen Touch light Switch 4 gang 220V

Product Overview

Description



Smart home Wifi Smart phone wall Glass Screen Touch light Switch 4 gang 220V







Features:



u111 is a WiFi Timer Switch which controls power ON/OFF of four load. The settings of delay off time are adjustable. It can be activated either by the button on its front or by a Smartphone. It is widely used for conference room, office, home living room, etc.



• High quality glass as faceplate, luxury and elegant;
• Operates on live line Input, and fits in a standard wall box;
• Easy to use. A gentle touch will turn on or turn off the load;
• Control over up to 4 loads. Each load can have a delay-off time of 30 seconds or instant on/off;
• Can be used as night light. All the buttons are always lit by blue backlights, so they are easy to find even in the dark;
• Classical 86 series design and easy installation.
• WiFi link to the smart phone with limitless working distance ;
• Costume color and pattern available; ABS-V0 flame resistance material; and Classical 86 series design and high quality build.
• Bi-directional communication with real time display of device status.













Specifications:





Input Voltage	220~240V(50Hz/60Hz)	Working Temperature	No-condensation 20-90%RH,-20℃~40℃
Wattage	1000W	Load Type	Any
Mounting Hole	60mm	Matching cassette	75*75*50mm
Dimension	86mm*86mm*50.50mm	Weight	139g







Installation Guide:











Operation Guide:



1. Download an Android APK and launch the program. A password matching u105 WiFi Timer Switch needs to be entered for the first sign-in. See above Fib. a.

2. Once the password is confirmed and gain access to the load type selection interface, click to select the right load type to be controlled. See above Fig. b.

3. Once load type is selected and enter the control interface, click the icon to control the load. See above Fig. c.
