Australian Standard Building Materials AAC ALC Floor Panel

Product Overview

Description

 Australian Standard Building Materials AAC ALC Floor Panel



Product Description

AAC Panel is for Autoclaved Aerated Concrete Panel, which are made from sand, cement, lime and gypsum.AAC Wal Panel is steel reinforced and lighweight. Eastland AAC Wall Panels can be easily cut,

drilled, screwed and grooved. Eastland AAC panels may be well used as external wall, internal wall, floor,

roof, cladding, fence etc . AAC wall panels have been widely used in various buildings such as residential,

commercial, industrial buildings and projects in China and many other countries.

Proterties Of AAC Wall Panel:
  - Good strength
  - Lightweight
  - Sound Insulation
  - Heat insulation
  - Anti-Vibration
  - Fireproofing
  - Environment friendly

Standard Thickness of  AAC Wall Panels:
  - 50mm, 75mm, 100mm, 120mm, 150mm, 200mm, 240mm, 250mm, 300mm

Strength level	A2.5	A3.5	A5.0	A7.5
Volume density level	B04	B05	B06	B07
Desiccated level	≤425	≤525	≤625	≤725

















Full name	Autoclaved aerated AAC panels
Width	600mm
Type	For wall,floor and roof
Thickness	50/75/100/125/150/175/200mm
Usage	Household Wall , Partition Wall , Fence
Length	Depend on thickness and usage
Color	White
Dry Density	Less Than 500kg/M3
Dry Thrinkage	0.48mm/M
Thermal Conductivity	0.13W/M*K





Packing&Shipping
Reinforced deformed bar AAC Exterior Interior Wall Panel
1)Packaging Details: plywooden pallet with conner protectors on all sides , outside with polybag.
2)Delivery Detail: within 10 days after payment


ALC panel specification:
AAC block supplier autoclave aerated concrete block aac panel

Item		Parameter Index Specifications
		50	75	100	125	150	175	200
1	Anti-impact capacity/times	≥5	≥5	≥5	≥5	≥5	≥5	≥5
2	Compressive strength/Mpa	≥3.5	≥3.5	≥3.5	≥3.5	≥3.5	≥3.5	≥3.5
3	Softening coefficient	≥0.8	≥0.8	≥0.8	≥0.8	≥0.8	≥0.8	≥0.8
4	Surface density(kg/m2)	≤70	≤70	≤90	≤90	≤110	≤110	≤130
5	Moisture rate(%)	≤10	≤10	≤10	≤10	≤8	≤8	≤8
6	Dring shrinkage value(mm/m)	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5	≤0.5
7	Hang force(N)	≥1000	≥1000	≥1000	≥1000	≥1000	≥1000	≥1000
8	Sound insulation capacity in the air(dB)	≥35	≥35	≥40	≥40	≥45	≥50	≥55
9	Fire endurance(h)	≥1.5	≥1.5	≥2.5	≥2.5	≥3.0	≥4.5	≥6.0
10	Heat transfer coefficient(w/m2.k)	≤2.0	≤2.0	≤2.0	≤2.0	≤2.0	≤2.0	≤2.0
11	Inner radiation index	≤1	≤1	≤1	≤1	≤1	≤1	≤1
12	Outer radiation index	≤1	≤1	≤1	≤1	≤1	≤1	≤1
13	Frost resistance (shall show no visible cracks and surface without change)	_	_	shall show no visible cracks and surface without change
14	The combustion properties (A1 or A2)	_	_	A1 or A2





We own fullly automaic producton lines and most advanced technology in the word.

We have been exporting the panels to lots of countries for many years with very good reputtion.



Should you have further enquiry, please just feel free to contact with us.

We look forward to establishing long term business relationship with you!
