Fully Automatic Cardboard Paper Plate Making Machine From Wuxi Mechanical
- Category: >>>
- Supplier: Wuxi City Yalian Honeycomb Machinery Plant
Share on (60514200872):
Product Overview
Description
Product Description
Fully Automatic Cardboard Paper Plate Making Machine From Wuxi Mechanical
Paper plate or flat paper board laminating machine :
Full automatically flat paper board laminating machine can make 2 or 4 or 6layers paper laminated at same time. The board after this laminating machinery is very flat, which is no bubble or wrinkles. We export this paper board machine to Japan, it is one of the advanced technique paper laminating machine in packing field.
model | 1300mm | 1450mm | 1650mm |
Max laminated layers | 4 | 4 | 6 |
Max laminated width | 1350mm | 1450mm | 1650mm |
Laminated thickness | 1-3.5mm | 1-3.5mm | 2-4mm |
Laminated speed | 0-20m/min | 0-20m/min | 0-20m/min |
Tolerance | ±1mm | ±1mm | ±1mm |
Installed power | 40kw | 65kw | 45kw |
configuration | Double paper rollers 2pcs Glue machine Double-roller pressing machine Twin-cast pressing machine Fixed length cutter Finished boards conveyor
| Double paper rollers 2pcs Glue machine Four groups pressing machine Cross cutter in step Twin-cast heating & pressing stacker | Double paper rollers 3pcs Glue machine Double-roller pressing machine Twin-cast pressing machine Fixed length cutter Finished boards conveyor
|
