Solvent extraction process different oil seeds: soybean, rice bran, peanut, sesame, sunflower seed, rapeseed, cotton seed, corn germ, copra, castor bean and so on.

We can product whole set cooking oil press machine, cooking oil extraction machine and cooking oil refining machine. Our cooking oil machine have been exported to more than 20 countries and regions, like Italy, Macedonia, Turkey, Iran, Egypt, Mexico, Ecuador, Haiti, Congo, Uganda, Nigeria, India, Pakistan, Thailand, Malaysia, Bangladesh, etc.

(1) Solvent pumps: continuously spray solvent to the rotary-type extractor
(2).Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be dissolved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).
(3). DTDC: usd to separate the solvent from the wet meal.
(4). Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , and then add 10% saline water to it. The phospholipid and impurities in the miscella will react with the saline wter, at last the reactant precipitate, reaching the goal of purifying.
(5). Miscella tank 2nd: the purified miscella will be pumped into it.
(6). Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.
(7). condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.

Spray and soak the pre-pressed cake with solvent so that oil fats can be dissolved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).

This loop type oil extractor is suitable for large capacity, such as when capacity is above 200t/day.

The loop-type extractor adopts a chain-drive system, it is suitable for the prepressing and extraction of high content oil and the direst extraction of low content oil. Like the rotocel extractor, the structure of loop type extractor is designed to reduce power consumption, maintenance requirements and noise. However, this extractor utilizes percolation-style filtration. Rotation occurs at the bend of the machinery for efficient procesing.

1.It is the most simplified structure of the same type of extractor
2.Replaced with a false bottom plate fixed grid,reducing the movement mechanism,high safe operation rate,work reliably.
3.Has a “self-cleaning”effect,clean up grid plate without downtime.
4.It can increase the leaching time of the material,reduce residual rate.
5.It can increase the loading factor,increase production.

(1) The material (for pretreatment) is sent to rotary extraction by the scraper conveyor. The material will extracted by the solvent or mix oil. After this step, we will get meal and mix oil.
(2) Meal is sent to toaster. Through the toaster, the solvent in the meal will separate from the meal. The solvent goes to condenser and is recycled to rotary extraction.
(3) After the mix oil from the rotary extraction enters into 1st evaporator and 2nd evaporator, most of the solvent in the mix oil is separated.
(4) The mix oil from 2nd evaporator goes to stripping tower and almost all the solvent is separated. From the stripping tower, we can get crude oil and solvent. The solvent is sent to condenser and is recycled to rotary extraction.

Pre-Sales Service

* Inquiry and consulting support.

* Factory and machine layout design.

* View our Factory.

After-Sales Service

* Training how to install the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Products Name with link

91.8% Response Rate

Henan Doing Mechanical Equipment Co., Ltd is one leading producer of oil equipments in our country, also one unit exempt from quality examination. Our company service includes technology design, installation and debugging, technical training, relocation of oil plant, technology reform and turnkey project.
