  • F20AFWS 20HP 4 stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4 stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor
F20AFWS 20HP 4-stroke short shaft outboad engine boat motor outboard motor

F20AFWS 20HP 4 stroke short shaft outboad engine boat motor outboard motor

Share on (60516089588):


Price:

Quantity:


Product Overview

Description


Product Description

PARSUN’S 20 HP outboard offers greater flexibility and durability. Start-in-gear prevention, front shift and a flushing device make it convenient to operate. On the water, you’ll enjoy the easy control, low fuel consumption, low noise and vibration.

\t
ITEM
\t
F20AFWS
\t
Engine type
\t
4-stroke,2-cylinders, OHC
\t
Displacement
\t
362 cc
\t
Bore x Stroke mm(in.)
\t
63.0×58.1(2.48×2.29)
\t
Max output kw(hp)
\t
14.7(20)
\t
Full throttle RPM range
\t
5000~6000
\t
Transom height mm(in.)
\t
381(15.0)
\t
Ignition system
\t
CDI
\t
Starting system
\t
Manual start + Electric start
\t
Steering system
\t
Remote control
\t
Gear shift
\t
Forward-Neutral-Reverse
\t
Gear ratio
\t
2.08 (27/13)
\t
Trim and tilt system
\t
Manual,4 positions/Shallow drive
\t
Max fuel consumption
\t
6.9 L/h
\t
Fuel tank capacity
\t
24L
\t
Sump oil capacity
\t
1.6L
\t
Gear oil capacity
\t
300cc
\t
Dry weight
\t
54.7kg
\t
Recommended transom height
\t
381mm(15 in.)
\t
Overall width mm(in.)
\t
420(16.5)
\t
Propeller options*
\t
3-9.25 x 8" or 3-9.25 x 10" or 3-9.25 x 11"

Main Features

1. Blow-By Gas Reburning System - clean
2. Prime Start - Sure Start
3.10A High Output Alternator - convenience
4. Single Operation Steering Friction - convenience
5. Strong Tiller Handle - reliability durability
6. Start-In-Gear Prevention - convenience
7. Labyrinth Exhaust System - low noise
8. Large Steering Angle - maneuverability
9. Front Shift - convenience
10. Water-cooled Fuel Pump - reliability durability

11. Flushing device - convenience
12. Over-Rev Limiter Overheat Warning Low Oil Pressure Warning - reliability
13. Quiet, through the propeller hub exhaust
14. Ultra low emission, CE and EPA approved
15. Quality 24L fuel tank with hose

Detailed Images

Water cooling system

Add water cooling channel and better water cooling system, so the power performance is better. The location of inlet of cooling water is at the bottom of Anti-swirl plate, which can prevent the impurity from going


Gear shift system

Gear shift system is assembled on the bottom, and it is convenient for maintenance..

Idle labyrinth exhaust chamber

When the engine is idling exhaust gas is expanded through a labyrinth, greatly reducing noise..

Shallow water drive

The outboard can be lifted and set at an angle preventing it from hitting the bottom when operating in shallow water.

Certifications

Parsun products meet the latest USA EPA emission standards and Europe CE standards as well.

Parsun company has obtained the ISO certificate.


Related Products

4HP 4-stroke outboard motor


6HP 4-stroke outboard motor


40HP 4-stroke outboard motor


Packing & Delivery
\t
Packaging
\t
Size
\t
116.5 (L) * 75 (W) * 48.5(H)
\t
Weight
\t
72KG
\t



Packaging Details
\t
The normal package is carton and foam (Size: L*W*H) for full container order. If export by the LCL, we will use man-made plywood boxes or pallets to protect the outboards.  If container is too tight, we will use PE film for packing or pack according to customers' special requests.
Our Service

Pre-Delivery Service

*24x7 inquiry and consulting support.

* Sample testing support.

* View our factory.

After-Sale Service

* 2-5 days free training program of maintenance, service and repair in our Suzhou plant.

* Engineers available to service outboards overseas.

Parsun technique core team, led by our Chief Engineer, have experience of outboards since 1968 and cooperated with OMC (the original manufacturer of Johnson and Evinrude outboard engines, merged by BRP) to develop critical components for high-power outboard engines in last 90s.

The Parsun brand has been registered and protected in USA, Canada, and over 100 other countries.

FAQ

>>What models of outboards do you have?
At present, we have gasoline outboards, kerosene outboards and electric outboards.
On gasoline outboards, we have both two-stroke and four-stroke outboards in mass production.
Four-stroke: 2.6, 4, 5, 6, 8, 9.8, 9.9, 15, 20, 25, 40HP.
Two-stroke: 2, 2.5, 3.6, 4, 5, 5.8, 6, 8, 9.8, 9.9, 15, 20, 25, 30, 40, 60, 75, 85 and 90HP.
On electric outboards, we have 5, 7 and 9.9HP.
On kerosene outboards, we have two-stroke 9.9, 15 and 40HP.

>>Do you have forward control outboards with electric start for the market?
Yes, we have forward controls with electric start from 8HP and above.
>>Do you have CE and EPA approvals?
Yes, we have both of them.
>>Are you a factory or trading company?
We are the manufacturer and exporter. Providing parts and technical support are a vital part of our business.
>>How long have you been in this business?
We started to develop outboard engines from 2002 and commenced the mass production in the beginning of 2006.
>>What's warranty period?
We provide warranty for both commercial use and pleasure use. Terms vary on different markets.
>>Can you supply spare parts?
Yes, as we are the original manufacturer.
>>Have you tested each piece of outboard before delivery?
Each new model of outboard motor has passed over 500 hours of rigorous endurance testing, before commencement of mass production. Each outboard has been tested for at least 1 hour before they go off production line.
>>What is your lead time?
2 weeks in low season, and 1~2 months during peak season.
>>What's your supply capability for outboard engines?
8000pcs per month.
