microwave switching power supply for 1500w magnetron
- Category: >>>
- Supplier: Hnnan Xinhang Microwave Technology Limited Company
Share on (60519588182):
Product Overview
Description
1500w microwave siwtch power supply, inverter board, AC DC converter
Product Parameters
| Input | Input voltage | 176Vac~264Vac |
| Input current | 10A Max | |
| Frequency | 47Hz~63Hz | |
| Power factor | >0.95 | |
| Leakage current | <250uA | |
| Output | Rated output power | 1500W |
| Rated anode high voltage | 4200Vdc | |
| Rated anode current | 0.35A | |
| Filament voltage | 3.3V | |
| Filament current | 10A | |
| Start-up time | <5S | |
| Operating/storage environment | Operating temperature | -20℃~+50℃ |
| Type of cooling | Air cooling | |
| Storage temperature | -30℃~+85℃ | |
| Related humidity | 5%~95% | |
| Altitude | 3000m | |
| Weight | 3500g | |
| EMI/EMC | EMI | EN55011 CLASS A |
| EMS | EN61000-4-2,-3,-4,-5,-6,-8,-11 | |
| Protection | Over current | Y |
| Over voltage | Y | |
| Over-temperature | Y | |
| Arcing protection | Y |
Product image:
AC connection terminal:
Communication port
Installation size:
Nofication: The standard filament wire is long 1.8m; it could be customized accrording to customization requirements
Product features
1. Energy-efficient, save electricity by 22% maximally;
2. Highly reliable design, multiple protections inside;
3. Wide power output range, 100W-1500W continuously adjustable;
4. Self diagnosis inside, fault upload function;
5. CQC, CE compliant.
Packaging & Shipping
1500w microwave siwtch power supply, inverter board, AC DC converter
we can accept the international order ,we can ship to our coverage zone.
1. we guarantee that the goods will be send out within 5 days if there are goods in stock .
2. the shipping time is depends on buyer's country, customs clearance time and other conditions; such as Force Majeure. if you don't receive the goods ,please contact your customs, and your local shipment company. Maybe you can get the goods quickly.
Our Services
1500w microwave siwtch power supply, inverter board, AC DC converter
we have a strong technical group to keep good quality of the goods. Even this, in order to provide excellent service to our customers, we also orgnise after-sales service group to help customers in time.
Company Information
1500w microwave siwtch power supply, inverter board, AC DC converter
Henan Xinhang microwave technology CO,.LTD main products including Microwave drying and sterilization equipment, microwave magnetron, transformer, high voltage silicon stack, oil cooling transformer group, waveguide microwave and other components. Especially our magnetron water cooling jackets and microwave transformer groups(magnetron power supply) got patents from the State Intellectual Property Office in 2012.
