Aluminum Pilfer Proof ROPP Screw Cover Making Machinery China Supplier
- Category: >>>
- Supplier: Jiujiang Gaoxin Metals Packing Mechanism Co. Ltd.
Share on (60520746469):
Product Overview
Description
Aluminum Pilfer Proof ROPP Screw Cap Making Machinery China Supplier
Aluminum Pilfer Proof ROPP Screw Cap Making Machinery China Supplier
Aluminum Pilfer Proof ROPP Screw Cap Making Machinery China Supplier
Product Description
GX16T Horizontal Punch(Second Stretching)
| Production capacity | 100-140/minute |
| Motor power | 1.5KW |
| Size | 1500*700*600mm |
| Weight | 1190kg |
Usage: The machine is used for second stretching for processed caps.
Related Machines:
NCP-008 NC Punch(25T)
Technical Parameter:
The feeding of materials,tinplates or aluminum plates to this punch is manual.
(1)NC table
| Max. Speed of Arm and Clamp | 36m/min |
| Feed Precision | ±0.1mm |
| Working Voltage | 380V,50HZ |
| Rated Power | 2KW |
| Outline Size(L*W*H)(NC Unit) | 1740*2340*1045mm |
| Weight(NC Unit) | 1200kg |
(2)25T press
| Nominal presure | 200KN |
| Slide troke | 70mm |
| Frequency of slide stoke | 50-100times/min |
| Power | 3KW |
| Dimensions(L*W*H)(mm) | 1660*1280*2080 |
| Weight | 2300kg |
GX2GK3Z Automatic Knurling & Ruling Machine
Technical Parameter:
| Production Capacity | 100-150caps/min |
| Motor Power | 0.12KW |
| Overall Dimension | 700*450*1260mm |
| Weight | 160KG |
This machine is applied for the knurling and ruling of the figurate caps.
28*18mm Pilfer Proof Cap Drawing
Products Produced by The Equipment
