symmetric biaxial carbon Fiber cloth 300 gsm

Product Overview

Description

We can supply  double bias carbon Fibre cloth  300gsm for composite application ,

such as car parts and boat and shoes parts and sporting goods

the fiber tow is from toray ,toho ,mitsubishi and formosa.......



The FAW is from 150gsm~1000gsm

width is 127cm

roll length is 50m

fiber direction +45 /-45



double bias carbon Fibre cloth  application are as follows
1. carbon fiber yacht parts. 2. carbon fiber Wind turbine blade.
3.carbon car parts: hood,front fender,steering wheel,gear shift,mirror cover,trunk cover.
4. carbon boat parts:mast,kayak,loom blade,boat shell. 5. sporting goods parts:snowboard,skateboard,skiboard.
6. construction retrofitting:carbon fiber reinforced building and bridge and factory base.



If you need more detail information.

please kindly contact us..





thanks





oliver Chou

JINSOR multiaxial carbon fiber fabrics detail specifications
Multiaxial carbon fiber fabrics application are as follows
1. carbon fiber yacht parts. 2. carbon fiber Wind turbine blade.
3.carbon car parts: hood,front fender,steering wheel,gear shift,mirror cover,trunk cover.
4. carbon boat parts:mast,kayak,loom blade,boat shell. 5. sporting goods parts:snowboard,skateboard,skiboard.
6. construction retrofitting:carbon fiber reinforced building and bridge and factory base.

Item name	Fiber orientation	Each layer weight(g/m2)	Stitched fiber weight(g/m2)	Total fiber weight(g/m2)	Fabric width (cm)	Fiber	Photos
CX150	+45/-45	75	7	157	127	12K spread tow Toray,Formosa Mitsubishi
CXT230	+45/90/-45	75	7	232	127	12K spread tow Toray,Formosa Mitsubishi
CX200	+45/-45	100	7	207	127	12K spread tow Toray,Formosa Mitsubishi
CXT300	+45/90/-45	100	7	307	127	12K spread tow Toray,Formosa Mitsubishi
CX250	+45/-45	125	7	257	127	12K spread tow Toray,Formosa Mitsubishi
CXT380	+45/90/-45	125	7	382	127	12K spread tow Toray,Formosa Mitsubishi
CX300	+45/-45	150	7	307	127	12K spread tow Toray,Formosa Mitsubishi
CXT450	+45/90/-45	150	7	457	127	12K spread tow Toray,Formosa Mitsubishi
CX400	+45/-45	200	7	407	127	12K spread tow Toray,Formosa Mitsubishi
CXT600	+45/90/-45	200	7	607	127	12K spread tow Toray,Formosa Mitsubishi
CLXT800	+45/90/-45	200	7	807	127	12K spread tow Toray,Formosa Mitsubishi
CX600	+45/-45	300	7	607	127	12K spread tow Toray,Formosa Mitsubishi
CXT900	+45/90/-45	300	7	907	127	12K spread tow Toray,Formosa Mitsubishi
CXLT1200	0/+45/90/-45	300	7	1207	127	12K spread tow Toray,Formosa Mitsubishi
