Underwater TV systems Composite Cable 300V 2 x 1.34 3 x 0.22 COAX75 OHM
- Category: >>>
- Supplier: Shandong Universal Cables Limited
Share on (60525691891):
Product Overview
Description
Product Description
Underwater TV systems Composite Cable 300V
2x1.34+3x0.22+COAX75 OHM
Application
The cable contain coaxes, power conductors to allow cameras, lights and pan & tilt units to be powered,controlled and video images carried to the surface. The cables all have Polyurethane outer jackets,allowing them to be easily moulded to connectors to make underwater cable harness assemblies.The composite cable for use in hostile marine environments
Construction:
Part 1: 1.34mm 2 2 Cores
1. Conductor: Tinned copper wire (TC)
2. Insulation: High density polyethylene(HDPE)
3. Insulation Diameter: 2.25mm
Color: Blue, Brown. Other color upon request
Part 2: 0.22mm 2 3 Cores
1. Conductor: Tinned copper wire (TC)
2. Insulation: High density polyethylene(HDPE)
3. Insulation Diameter: 1.20mm
Color: Green, Yellow, Grey. Other color upon request.
Part 3: 75Ω Mini coax
1. Conductor: Tinned copper wire (TC)
2. Insulation: Cellular Polyethylene (Foam PE), Color: White
3. Dielectric diameter : 1.7mm
4. Overall shield: 0.1mm tinned copper braid shield ,coverage>95%
5. Sheath: High density polyethylene(HDPE)
Color: Black. Other color upon request
Part4: Cable Assembly (Part 1+Part2+Part3)
2x1.34mm2 cores, 3X0.22mm2 cores and 1 x 75Ohm mini coax laid together along with water blocking swellable yarns to form circular profile.
Part 5: Protective tape: Polyester Tape 100% Coverage
Part6: Bedding Layer: Polyurethane.(PUR) Colour: Orange, other color upon request.
Thickness of Bedding layer: 1.2 mm nominal
Part7: Renforcement: Vectran yarn braid.
Part8:
Outer Jacket: Polyurethane.(PUR). Colour: Orange, other color upon request.
Thickness of Outer Jacket: 1.5 mm nominal
Marking: UNDERWATER COMPOSITE TV SYSTEM CABLE 2x1.34+3x0.22+COAX75 OHM UNIVERSAL
YR2016 XXXXM. Other as per customer requirement on order.
Packing length: 1000m/Drum, or as per customer request
Constructional Data
Operating Temperature: -40℃C to +80℃ Overall Diameter: 13,5 mm ±1.0 mm
Weight in air: 260 kg/km nom. Weight in seawater: 88kg/km nom.
Min. bending radius: 5X Diameter Static Min. bending radius: 10X Diameter Dynamic
Depth rating: 5000m Voltage: 300V
More details please contact us. helen (at) uecable.com
