Manual Mechanical Jack, Lift Rack Jack, Track Jack for railway

Product Overview

Description



 China Hand Manual Mechanical Jack, Lift Rack Jack, Track Jack



Specifications



1. Loading capacity: 5T, 10T, 15T



2. Operation: Manual



3. This mechanical track jack designed to lift all types of the rails, and shunting installed on





concrete, wooden or iron crosspieces.



4. Material: A. Body: Cast steel, cast iron. B. Gear: 45# steel, alloy steel, spring steel.




5. Different material decides different price





applicance





a. Apply to the complementary set, an axle railway bridge installation, and vehicles, equipment,



heavy lifting with.



b. The structure is simple, easy to use, safe and reliable, and many machine etc. It is a kind of



 hoisting tools that are widely used.



c. principle of work the machine is manual type one type of hoisting tools, compact structure,



reasonable use a joystick to move up and down swinging the claw, with the tooth claw, promote

the linkage with rack up or down, and then the weight.





Technical parameter



Type	QD5	QD10	QD15
max. lifting capacity of the  top	5T	10T	15T
max. lifting capacity of the hook	2.5T	5T	7.5T
max. lifting stroke	160mm	180mm	280mm
top height	345mm	410mm	580mm
hook height	43mm	45mm	60mm
