2020 1 Roller industrial washer/dryer/ironer/folder for school table cloth with after sale service

Product Overview

Description

 Laundry Equipment bed sheet flatwork ironing machine steam heating 1500mm-3300mm



Advantages:



1, For bedsheets, quilts, tablecloth, towel, curtain, bath towel etc.

2, Large diameter(Φ800mm) roller drum,stainless steel, surface is smooth.

3, Frame and auxiliary,high-quality steel carbon structures, strong and durable.

4, Variable frequency, variable speed, according to fabric, moisture, steam supply, etc.

5, Simple control with Start/Stop button.

6. Sealed rotary joints, prevent leakage, safety and reliability, save energy.

7. Three-phase al system, overload , voltage and short circuit , emergency stop switch.

8,The fence and travel switch in the input part, reduce fatigue, misuse and the risk.

9, Pressure roll with guiding ribbons,superior ironing quality,nomex ironing belts.

10, Heated: steam, , gas for your choice.

11, Roller quantity: single,double or tripple



if you want to know more  about our products / factory department,

 you can visit our facebook:

https://www.facebook.com/profile.php?id=100012465934180

  you can also visit our linkedin:

https://www.linkedin.com/?trk=360-mainlink



Model	TPI-1600	TPI-1800	TPI-2200	TPI-2500	TPI-2800	TPI-3000	TPI-3300
Max Ironing Width(mm)	1600	1800	2200	2500	2800	3000	3300
Roller Diameter(mm)	800	800	800	800	800	800	800
Number of Roller(pcs)	1	1	1	1	1	1	1
Ironing Speed(m/min)	0-6	0-6	0-6	0-6	0-6	0-6	0-6
Steam Consumption(kg)	50-70	50-80	60-90	70-100	80-110	90-120	100-130
Steam Presure(Mpa)	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6	0.3-0.6
Main Motor Power(kw)	1.5	1.5	1.5	1.5	1.5	1.5	1.5
Inverter Power(kw)	1.5	1.5	1.5	1.5	1.5	1.5	1.5
Max Iron Smooth Temperature(°C)	158/200	158/200	158/200	158/200	158/200	158/200	158/200
Heating power(kw)	22.5	24	27	30	32.4	34.2	34.5
Net Length(mm)	2560	2750	3550	3750	4020	4220	4420
Net Width(mm)	1500	1500	1280	1280	1280	1280	1280
Net Height(mm)	1350	1350	1300	1300	1300	1300	1300
Net Weight(kg)	1500	1600	1700/2300	1800/2600	1950/2900	2000/3100	2100/3200
Gross Weight(kg)	1650	1800	1900/2500	1950/2800	2050/3100	2200/3300	2300/3400
