disposable Mattress Making Machine

PERFORMANCE CHARACTERISTICS:

1.\tTouch-control, PLC program control, replace only need to enter the length of the data can be extremely simple. Easy to operate.

2.\tAdopts step less control of the governor which can adjust the thickness and weight.

3.\tThe cotton core pattern repression does not fall off, clearly and firmly.

4.\tThe cotton core can be added to the polymer (SAP) quantitative add, weight adjustable.

5.\tThis machine is full servo motor control, the length of any adjustable, high precision.

6.\tFolding size：width folding: 1/2,1/3 or 1/4(can be changed on machine)

Length folding: 1/2 or 1/3 (one machine only fit for one folding size)

7.\tThe machine can produce toilet paper, laid paper, wood pulp, cotton mattress absorber.

TECHNICAL PARAMETERS:

1.\tPower Supply：380V/50HZ

2.\tPower：55kw（Include a hot melt glue machine）(without wood pulp section:45kw)

3.\tDesigned Speed：80m/min

4.\tOptimum Speed：60m/min

5.\tDimension：Main machine：11300*2500*2400mm

Feeding framework ：3000*1200*1050mm

Convey belt：2000*300*650mm

6.\tWeight：18t(without wood pulp section 12t)

7.\tYung press：≥0.6mpa 1.2m³/min

8.\tSpecifications：Width（300-800mm）,Length（400-1500mm）
