Ringder HC 110M Digital Humidity Controller for Humidifier and Dehumidifier

Product Overview

Description

Humidity Controller for Humidifier HC-110M

This product has 220V10A, 220V30A, 12V10A, 12V30A, 110V10A, 110V30A, 24V10A and 24V30A type.

Xuzhou RINGDER Electrical Equipment co., LTD. is a science and technology enterprise, which is independent research and development, production and manufacture of electronics. RINGDER, based on electronic science and technology at the beginning of establishment, provides a series of solutions with the temperature, humidity, time, infrared, displacement, PID, linear fuzzy control for the refrigeration, HCVA, household appliances, food machinery, aquarium and reptile equipment, suana room and foot spa etc. other industries.

RINGDER HC-110M 220VAC10A Dehumidification and Humidification Universal Digital Humidity Controller Regulator Sensitive Switch

Model: HC-110M

Features:

• Adopt world famous brand humidity sensor


• High and low humidity alarm

Parameters:

• Humidity measuring and controlling range: 0%~99%


• Relay capacity options: 10A or 30A


• Power options: 220VAC or 110VAC



• Input: 1 humidity sensor; sensor wire: 1.1m(standard)


• Accuracy: ±3%; Resolution: 0.1%


• Consumption: ≤3W


• Cut-out size: 71×29(mm)


• Ambient requirements: temperature: -10~60°C; humidity: 20~85% (No condensate


• Output: resistive load≤1100W/220V, inductive load≤275W/220V, filament lamp≤220W/220V

Package Includes:

Friendly Reminder:

• We are factory and can provide customized service for all of our products with reasonable price.

We also have a plug in humidity controller HC-210, please check the information below.

Digital Day/Night Humidity Controller

Model: HC-210

Features:

• Blue tape LCD display, simple operation


• Stable imported humicap sensor, humidity adjusted per 0.1%


• Two timers can be set during 24 hours


• Uses a inbuilt real-time clock to control the light so simulating the day and night as in the real environment


• Can be set with a separate day and night humidity


• Two kinds of humidity alarms, mute function available


• Can be used in both wet and dry environments


• Backlight auto shut down if without operation for 10 minutes


• Small in size making it stylish and discrete

Parameters:

• Humidification and dehumidification mode switchable


• Controlling range: 0.0~99.9%


• Measuring range: 0.0~99.9%


• Resolution: 0.1%; Accuracy: ±5.0%


• Over humidity alarm: 0.0-20.0%(can be modified)


• Humidity differential: 0.0-10.0%


• Time unit: hour (24:00 format)


• Relay Capacity: 10A or custom


• Input voltage: 220VAC±15%,50/60HZ(Optional:110VAC)


• Product consumption: ≤3W


• Control load: ≤1200W/220VAC


• Two independent sockets –First socket (nearest power cable) is for humidification or dehumidification output; Second socket is for the timer output (for lighting for example). Optional: EU, USA, UK, AU or other type

• 1 x thermostat(power strip included)


• 1 x user manual
