16 Channels Video Balun price, hd video balun AHD TVI CVI 1080P 5MP over cat5/cat5e/cat6 utp cable

Overview:

The video balun hub is a passive (non-amplified) device that allows the transmission of real-time CCTV HD video signal via cost-effective Unshielded Twisted Paired (UTP) cable. It is compatible with all HD-TVI, HD-CVI, AHD and CVBS analog cameras, supports pluggable screw terminal or RJ45 connections. Used with single channel HD passive video transmitter,  is capable to receive 16 channel live CCTV HD video signal from camera end via one UTP cable.

The superior interference rejection and low emissions of the balun allow video signals to coexist in the same wire bundle as telephone, datacom,or low-voltage power circuits. This allows the use of a shared or existing cable plant. This device is built-in surge suppressor to protect video equipment against damaging voltage spikes and provide noise immunity to ensure quality signals without disturbing "hum-bars"

•  High Quaility product,Brand New.

• 16 channel Passive video balun.

• Video transmission via UTP CAT5 cable.

• Full-mition CCTV video at distances up to 300m(max)

• 10-20% wire costs saved.

• NTSC,PAL&SECAM video format compatible

• Outstanding interference rejection and transient protection.

• Male BNC allows connection directly to the camera or DVR.

• Ave lots of Extra Cable Money.

• Smart Buildings

 • Intelligent Transportation System

 • Security and Surveillance, CCTV System

 • Connection of Sub-network for Surveillance Center

 • High Way & Toll Station Surveillance

 • High Quality Video Conference

Shippment

Warranty

Service

We always do strict quality inspection on every item!!!!

Attending exhibitions to show newest products!!!!

We are original factory producer, not a distributor!!!

So please feel free to contact us for your any interests! thank you very much!!!
