China Top 3 Aerial Ladder Fire Truck with Advanced Technology and Stainless Steel
- Category: >>>
- Supplier: Shanghai Jindun Special Vehicle Equipment Co. Ltd.
Share on (60529101555):
Product Overview
Description
China Top 3 Customize Aerial Ladder Fire Truck with Advanced technology and stainless steel
Product Description
1.Heavy aerial ladder truck, lifting hoist, rescue speed fast, no need to climb ladder
2. Equipped water and foam tank, fire pump, hydraulic control fire monitor, with high spraying function and completely fire fighting function
3. Rapid expansion
4. Gyrocompass leveling
5.Hydraulic and electric two ways control
| Name | Aerial Ladder Fire Truck | |
| Model | JDX5150JXFYT30 | |
| Chassis Model | OL11609QFRY | |
| MaxSpeed(km/h) | ≥9 | |
| Overall Size(mm) | 9930 x 2480 x 3660 | |
| Gross Weight(kg) | 15050 | |
| Number Of Seats | 6 | |
| Max.Power(kW) | 139 | |
| Main Performance Parameters | Rated Working Height(m) | 30 |
| Max Working Range(m) | 25 | |
| Luffing Scope° | -17°-75° | |
| Outrigger Span(mm) | 5280 x 4720 | |
| Weight Parameters | Axle Weight | 5270/15050 |
| Extinguishant Rated Load(kg) | / | |
| Carrying capacity | Number of work loading people | 400 kg/4 persons |
| Ladder | 800 kg/8 persons | |
| Fire Pump | Flow Rate(Us) | 20 |
| Pressure(MPa) | 1.4 | |
| Fire Monitor | Rated Flow Rate(Us) | 20 |
| Water Throw Range(m) | ≥48 | |
Product Process
Product Application
Certifications
Packaging & Shipping
Company Information
Shanghai Jindun is a professional fire protection enterprise,one of the largest fire protection equipment and fire fighting vehicle manufacturer.Our company owns a first-rate ultra-large modern factory, internationally advanced processing equipment, domestic and foreign sales networks and a powerful service system, gathers many top technicians and industrial experts, and has 112 types of products, including CAFS fire trucks, water tank foam trucks, rescue vehicles, gas supply vehicles and other general fire trucks.Our Company will give you best products and best service.
Contanct us
FAQ
| 1, Q: Why should we choose you ? |
A: We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting. |
B: We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur |
C: We have our own R&D team, production workshop, QC management team, international marketing team and after service team. |
D: We will provide the most professional and the best service on every business discussion and operation procedure. |
E: We can provide special design for different specification requirement according to different orders or tender documents. |
G: We have jointed ventures with Morita for 4 years, so the technology, design and quality are same with Morita. |
H: We have collaboration with various top enterprises of fire protection sector, Such as Darley, Rosenbauer, HALE, AKRON, Ekhart, etc. |
| I: Our Certifications: ISO, TUV, CCCF, SONCAP, CNAS, SGS,MH /T5002-9, MEP, CQC. |
| 2, Q: What's your Payment method? |
| A: T/T 30% deposit, balance will be paid by T/T before delivery |
| B: 100% L/C before start production |
| 3, Q: What logistics ways we can work for shipment? |
| A:We can ship fire trucks by various transportation tools |
B:We will go by sea to all main continents such as South America, Middle East, Africa, Oceania and Europe etc. |
C:Also we can ship trucks by road or railway to the neighborhood countries of China such as Russia, Mongolia, Kazakhstan, Uzbekistan etc. |
| 4, Q: What's the delivery time? |
A: 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model. |
| B: ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit. |
| C: European brand chassis 9 months upon receipt of advance deposit. |
| 5, Q: Can you provide the ISO9001 certificate or some others related? |
A: Yes. We have been exporting fire trucks for years. Rich experience for exporting to different countries like African market, Russia and South America. This helps us to know the importance of handling with various certificates. |
| 6, Q: How about warranty item? |
A: We could support you original spare parts. And also email or telephone assist in the following days. If necessary, our outwork engineer could go for technical assist. |
| B: 12 month whole vehicle warranty |
