Performance and characteristics
This machine used o print logo, stickers logo, computer form ,bill,aluminum foil, milk kraft paper,battery film,carton paper and so on,printed raw material thickness range to be 40-200g/m².Printing machine functional diversification, can do double-face print,adhesive sticker peeling print,UV glazing,indentation,die cut,coating,gold stamping,slitting and so ontechnology process.
This is ideal printing equipment for wine package,cigarette box,medicine box,make-up box,juice box,carton package(logo,box,bag,carton)
Model | ZXYT-41000 |
Maximum paper width | 1015mm |
manimum printing width | 1000mm |
printing repeat | 279.4-660mm |
Maximum unwinder diameter | 1524mm |
Maximum rewinder diameter | 1524mm |
Gearing | 1/8CP |
Maximum mechanical speed | 152m/min |
Drive | 11KW |
Lubricating system | Automatic |
Control panel | in the front of the press |
Air pressure | 100PSI |
Power requirement | 380VAC 3ph 50HZ |
Substrate | 40-200gsm paper |
