Hot New Chinese Lathe CZ1224G CZ1324G Mini Lathe Machine Price
- Category: >>>
- Supplier: Shandong Luzhong Machine Tool Co. Ltd.
Share on (60533401170):
Product Overview
Description
Product Description
The main performance characteristics:
1.Engineered from high grade castings
2.V way bed ways induction hardened and ground
3.Gap bed
4.Cross and longitudinal interlocking feed, enough safety
5.Inching switch for test running
6.Metric/Imperial threading available
7.Precise gear-driven headstock
Product main technical parameters:
1.Engineered from high grade castings
2.V way bed ways induction hardened and ground
3.Gap bed
4.Cross and longitudinal interlocking feed, enough safety
5.Inching switch for test running
6.Metric/Imperial threading available
7.Precise gear-driven headstock
Product main technical parameters:
Specifications | CZ1224 G | CZ1324G | ||
Swing over bed | mm | 305 | 330 | |
Swing over carriage | mm | 173 | 195 | |
Swing over gap | mm | 440 | 465 | |
Width of bed-way | mm | 182 | ||
Distance between centers | mm | 530 | ||
Spindle taper | MT5 | |||
Spindle bore | mm | 38 | ||
Step of speed | 9 | |||
Range of speed | rpm | 64-1500 | ||
Metric thread | mm | Closed box:11kinds(0.5~43.5) | ||
Norton box:15kinds(0.25~47.5) | ||||
Inch thread | T.P.I | Closed box:14kinds(7-1/2~48) | ||
Norton box:40kinds(4~112) | ||||
Range of feed amount | Mm/r | Closed box:0.051~0.303(0.002’’-0.012’’) | ||
Norton box:0.12~0.42(0.0047’’-0.0165’’) | ||||
Diameter of lead screw | mm | 22(7/8’’) | ||
Pitch of lead screw | 3mm or 8 T.P.I | |||
Saddle travel | mm | 510 | ||
Cross travel | mm | 150 | ||
Compound travel | mm | 85 | ||
Barrel travel | mm | 95 | ||
Barrel diameter | mm | 32 | ||
Taper of center | mm | MT3 | ||
Motor power | Kw | 1.1(1.5HP) | ||
Motor for coolant system’s power | Kw | 0.04(0.055HP) | ||
Machine(L×W×H) | mm | 1420x750x760 | ||
Stand (left)(L×W×H) | mm | 400x370x700 | ||
Stand (right)(L×W×H) | mm | 300x370x700 | ||
Machine | Kg | 380/430 | ||
