110cbm Propane Storage Tank LPG Tank and Dispenser Price

Product Overview

Description

110cbm Propane Storage Tank LPG Tank and Dispenser Price Call Ms.Pinky 0086 15897603919



We can Provide you the following LPG Gas Storage Tanks:

Our factory is a professional manufacturer for LPG tank truck, LPG trailer, LPG storage tank in China.

1. Our biggest capacity of LPG tank truck is 35.5cbm;

2. Our biggest capacity of LPG trailer is 59.3cbm;

3. the LPG storage tank is from 5cbm to 200cbm.



Our producing factory:

10cbm to 200cbm LPG TANK:

20cbm, 30cbm, 40cbm, 50CBM to 200cbmLPG tank:

56.14Cbm 59.3cbm LPG tanker semitrailer:

23.7CBM LPG TANKER SEMITRAILER:

Double axles 47cbm LPG tanker semitrailer

5cbm to 30cbm bobtail truck



we manufacture equipments for LPG STORAGE TANK FROM 20CBM T0 200cbm , LPG SEMITRIALER, LPG ROAD TANKER, LPG SEMITRAILER TRANSPORT TANKS AND SO ON.





More information, please contact with me.



0086 15897603919 Ms. Pinky

Main specification
Tanker body	Item	data	Itm	Data
	Filling medium	LPG	Kerb weight	20830kgs
	capacity	105m3	Loading weight	41895kgs
	Design pressure	1.71Mpa	Outside dimension(inner	3200*16*13016mm
	Thickness of body	15.54mm	diameter*thickness*length
	Thickness of head	15.82mm	Filling ratio	0.95
	Material	Q345	Hydraulic test pressure	2.14Mpa
	Corrosion allowance	1mm	Service year	15
	Hot treatment type	Stress relieved hot treatment	Filling ratio	420(50°C)
	105m3 LPG STORAGE TANKER



Main specification of 50MT 120CBM LPG STORAGE TANKS
Tanker body	Item	data	Item	Data
	Filling medium	LPG	Kerb weight	24700kgs
	capacity	120m3	Loading weight	50400kgs
	Design pressure	1.71Mpa	Outside dimension(inner	3200*16*15600mm
	Thickness of body	15.54mm	diameter*thickness*length
	Thickness of head	15.82mm	Filling ratio	0.95
	Material	Q345	Hydraulic test pressure	2.14Mpa
	Corrosion allowance	1mm	Service year	15
	Hot treatment type	Stress relieved hot treatment	Filling ratio	420(50°C)
	120m3 LPG STORAGE TANKER

The tank consist of the cylinder shell and standard ellipsoidal head. The tank’s material is high intension steel plate Q345R that is specially used in pressure vessel.



The double side auto-welding is adopted in tank’s main welding joints. The 100% x-ray checking shall be done to A and B kinds welding joints and shall accord with 2 grade requirements of JB4730 ‘Non-destruction testing for Pressure vessels’.



The fully magnetism checking or penetrate checking shall be done to C and D kinds welding joints and shall accord with Ⅰ grade requirements of JB4730. PWHT shall be done after the welding of tank .



The hydraulic test shall be done after the postweld heat treatment. The manhole of the tank is used for cleaning and maintenance of the tank’s inside. The baffles are mounted on the tank’s inside to prevent wave. The seat is welded on the tank’s bottom.







Accessories of LPG Tank:







With steel plate to anti waves to protect the Thanks body:







Hot treatment:

 The double side auto-welding is adopted in tank’s main welding joints. The 100% x-ray checking shall be done to A and B kinds welding joints and shall accord with 2 grade requirements of JB4730 ‘Non-destruction testing for Pressure vessels’.



More LPG STORAGE TANK at our factory for you Choice:







Delivery time: 15-20days after get the deposit or LC

Packing: nacked package, waxed before delivery by sea.

Documents: B/L, Commercial invoice, Packing list, Certificate of origin etc

 Our Bank Information:

 BENEFICIARY: HUBEI RUNLI SPECIAL AUTOMOBILE CO., LTD
Address: NO.77, century ave, suizhou city, hubei province
BANK OF BENEFICIARY: BANK OF CHINA, HUBEI BRANCH, SUIZHOU SUB BRANCH
ADDRESS OF BANK: NO.69 LIESHAN ROAD, SUIZHOU, HUBEI, CHINA
ACCOUNT NO.: 20310608092001
SWIFT NO.: BKCHCNBJ600



1. Water truck

2. Fuel tanker truck, Oil Truck, Tanker Truck

3.Fire engine truck

4.Truck mounted with crane

5.Dump truck,tipper,heavy duty truck

6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker

6. Bulk cement truck

7. Concrete mixer truck, mixer truck, cement mixer truck

8. Garbage truck, Self-loading garbage truck,garbage compactor truck,sealed garbage truck

9.Fecal suction truck,sewage suction truck

10. High altitude working truck

11. Chemical liquid truck

12. Van truck,insulated truck,refrigeration truck

13. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer,etc more than 300 types in total.



Our company covers an area of 110,000square metres, factory area of 25000m3, manufacturing capability 5000 sets every year, include sales branch, producing manage centre and more than thirty branches in China.



Our company has D grade spressure vessel manufacturing ability, and war industry manufacturing ability and got the certification in 2005, is the producing basic of Chinese Sinopec.

 our products not only gains the good reputations in domestic, but also be sold to oversea market, such as Qatar, Algeria, Bolivia, Burundi, Cameroon, Nigeria, Congo, East Timor, Ghana, Libya, Angola, O'zbekiston, South Africa, Afghanistan, vietnam, kazakhtan, Thailand, Mongolia, etc.

Our company contact infomration and offical website: www.runlitruck.com



More specs , photos, price, delivery time and other need,



please contact with Ms Pinky. Hotline: 0086 15897603919

Welcome to visit our company! suizhou city, Hubei Province.
