High Energy/Power Laser Mirrors
- Category: >>>
- Supplier: Beijing Dingsheng Brothers Technology Co. Ltd.
Share on (60535098286):
Product Overview
Description
- Product Name: High Energy/Power Laser Mirrors
- Substrate:UV grade fused silica, BK7
- Sl Surface Figure:λ/10 typical at 633nm
- Sl Surface Quality:20/10 laser quality
- S2 Surface Quality:Commercial polish
- Chamfer:0.25mm at 45°typical
- Coating Technology:Electron beam evaporation,dielectric multilayers
- Incident Angle:0° or 45°
- Clear Aperture:> 85% Of diameter
- Laser-Induced Damage Threshold:>3 J/cm2 (1.06μm,Ins)
Production description:
| Part No. | Diameter(mm) | Wavelength(nm) |
| SHR-S-0-01-A/B/C | 20/25.4/30 | 308 |
| SHR-S-0-02-A/B/C | 20/25.4/30 | 532 |
| SHR-S-0-03-A/B/C | 20/25.4/30 | 632.8 |
| SHR-S-0-04-A/B/C | 20/25.4/30 | 780 |
| SHR-S-0-05-A/B/C | 20/25.4/30 | 1064 |
| SHR-S-0-06-A/B/C | 20/25.4/30 | 1315 |
| SHR-S-0-07-A/B/C | 20/25.4/30 | 10.6um |
| SHR-D-0-01-A/B/C | 20/25.4/30 | 266/532 |
| SHR-D-0-02-A/B/C | 20/25.4/30 | 351/1053 |
| SHR-D-0-03-A/B/C | 20/25.4/30 | 532/1064 |
| SHR-D-0-04-A/B/C | 20/25.4/30 | 632.8/1064 |
