Blue tip WL20 thoriated tungsten electrode for tig soldering
- Category: >>>
- Supplier: Baoji Kedipu New Material Co. Ltd.
Share on (60537723400):
Product Overview
Description
Blue tip WL20 thoriated tungsten electrode for tig soldering
Specification
Grade | Oxide Addictive | Impurity % | Tungsten % | Color code | |
Name | Pct. | ||||
WP | N/A | N/A | <0.20 | The rest | Green |
WC20 | CeO2 | 1.8-2.2 | <0.20 | The rest | Gray |
WT10 | ThO2 | 0.80-1.2 | <0.20 | The rest | Yellow |
WT20 | ThO2 | 1.70-2.20 | <0.20 | The rest | Red |
WT30 | ThO2 | 2.80-3.20 | <0.20 | The rest | Purple |
WT40 | ThO2 | 3.80-4.20 | <0.20 | The rest | Orange |
WL10 | La2O3 | 0.8-1.2 | <0.20 | The rest | Black |
WL15 | La2O3 | 1.3-1.7 | <0.20 | The rest | Golden yellow |
WL20 | La2O3 | 1.8--2.2 | <0.20 | The rest | Sky blue |
WZ3 | ZrO2 | 0.2-0.4 | <0.20 | The rest | Brown |
WZ8 | ZrO2 | 0.7-0.9 | <0.20 | The rest | White |
WY | YO2 | 1.80~2.20 | <0.20 | The rest | Blue |
Dia. mm | 0.5 | 1.0 | 1.6 | 2.0 | 2.4 | 3.0 | 3.2 | 4.0 | 4.8 | 5.0 | 6.0 | 7.0 | 8.0 | 10.0 | 12.0 |
Length mm | 150 or 175 | ||||||||||||||
Choose the diameter according to welding current
Dia. | DC(A) | AC(A) | |||
in | mm | Cathode contacted (-) | Anode contacted(+) | Asymmetric waveform | Symmetric waveform |
0.04" | 1.0 | 15-80 |
| 10-80 | 20-60 |
1/16" | 1.6 | 60-150 | 10-18 | 50-120 | 40-100 |
0.079" | 2.0 | 100-200 | 12-20 | 70-160 | 60-130 |
3/32" | 2.4 | 150-250 | 15-25 | 80-200 | 80-150 |
1/8" | 3.2 | 220-350 | 20-35 | 150-270 | 120-200 |
5/32" | 4.0 | 350-500 | 35-50 | 220-350 | 170-260 |
3/16" | 4.8 | 420-650 | 45-65 | 240-420 | 220-340 |
1/4" | 6.4 | 600-900 | 65-100 | 360-560 | 250-450 |
Company Information
Our Wealth
1. 2001, we've been providing high-quality products & service for over 15 consecutive years. 2. The factory covers an area of 25,000 square meter. 3. We have over 80 employees, including a group of experts in non-ferrous industry. 4. We have a professional team foreign trade. |
A Glimpse of Our Equipment
Our Certificates
We welcome dear customers from all around the world with OEM&ODM service.
application
1. For producing electric light source parts and electric vacuum components. 2. For producing heating elements and refractory parts in high temperature furnaces. 3. For producing medical laboratory equipment. 4. Used as electrodes in the field of rare earth equipment. 5. Uesd in the manufacture of weapons. 6. Uesd for the thermalcouple protection tube in the high temperature furnace. |
Packaging & Shipping
| TNT, EMS, UPS, FedEx, DHL, air transport, sea transport and railway transport are all available.We will try our best to choose the most proper method to satisfy our customers' demands.Every order will be tracked until our products are well recived. |
Payment Terms
Our Services
Powder Mettallurgy
6 workshops: powder molding workshop, forging workshop, rolling workshop, vacuum furnace manufacturing workshop, machining workshop and cutting workshop, and 1 inspection center. 1 inspection center |
Vacuum induction smelting
| We can also make metal products through vacuum induction smelting process, for instance Nickel and its alloys. Combining with other equipment like forging machine, rolling machine etc, we can also make Nickel N4 & N6 plate, sheet, foil, strip etc. |
