1. Using exquisite craftsmanship and strict inspection standards, make the tinting of polycarbonate sheet more uniform.

2. The normal thickness of anti-UV layer is 50 micron. If for special projects, we can do 80 micron, or even thicker.

3. For polycarbonate solid sheet, the thickest we can do 20mm at present. Can meet your requirement for different situations.

4. To prevent pc sheets fade easily and extend service life, we use color master-batch instead of toner.

5. For raw material, we all use 100% virgin polycarbonate material. This helps us produce very high quality pc sheet without defects, and helps us gain good reputation among customers.










Solid Polycarbonate Sheet Specifications:


Thickness (mm)
Weight (kg/m2)
Mini-bending radius
 (mm)
Width
 (m)
Length
 (m)
Colour
1.1
1.32
234
1.22-2.1


no limited, It can be rolled like 30 meter




Clear/Green/Blue /Brown/Opal/Red /Yellow, or customize
2
2.4
360
1.22-2.1
3
3.6
540
1.22-2.1
4
4.8
720
1.22-2.1
5
6
900
1.22-2.1

≤5.8m for 20ft,
≤11.8m for 40ft
6
7.3
1080
1.22-2.1
8
9.6
1440
1.22-2.1


Solid Polycarbonate Sheet Techniacal Data:


Impact strength
850J/m
impact strength of solid PC sheets is 250 times of glass,
20-30 times of PMMA sheet
Light transmission
80%-90% for different thickness of clear color
UV resistance
50μm UV layer, can filter 99% ultraviolet radiation in sunlight
Coefficient of thermal expansion
0.065 mm/m°c
Service temperature
-40°c to 120°c
Heat conductivity
2.3-3.9 W/m2 °c
Tensile strength
>60N/mm2
Flexural strength
100N/mm2
Tensile street at break
>65mPa
Heat deflection temperature
140°c
Soundproof index
4mm thickness--27dB,5mm--28dB,6mm--29dB
