Affordable Price of Full Automatic A4 size Paper Roll Cutting Machine

Product Overview

Description

Affordable Price of Full Automatic A4 size Paper Roll Cutting Machine



   Application







This machine is applied to the non woven material,film,paper cutting.Widely used in bag making,printing and packaging industries.









Features:



1.The machine adopts stepper motor control of fixed length cutting.With electric optical tracking system



2.The machine light,electricity and one easy,cut-cut,high precision,mechanical stability ,low noise



3.Motor frequency control,automatic counting,alarm stop and other functions



4.Heavy quality tool cutting,product neat,without edges.






















 Mian Technical   (OEM accept, customize order accept)





MODEL	600	800	1000	1200	1400
WIDTH	100-500mm	100-700mm	100-900mm	100-1100mm	100-1300mm
LENGTH	30-1500mm
THICKNESS	PLASTIC FILM 0.01-0.5mm NON WOVEN 10-300G,PAPER 10-450G
SPEED	700-750pcs.min
PRECISION	±0.2-0.5mm
TOTAL POWER	2.2kw	2.5kw	3kw	7.5kw	4kw
WEIGHT	800kg	900kg	1000kg	1800kg	1300kg
DIMENSION	3200*1300*1500mm	3500*1500*1500mm	3800*1700*1500mm	4000*1900*1500mm	3800*2100*1500mm
