textile color matching light box color assessment cabinet the smallest Light Box in our range
- Category: >>>
- Supplier: Qinsun Instruments (shanghai) Co. Ltd.
Share on (60548547599):
Product Overview
Description
Product picture
Product Description:
Brief Introduction:
The consistency of the light sources in all VeriVide Colour Control Cabinets gives excellent viewing conditions for reliable colour critical decisions under consistent lighting.
The VeviVide CAC60 Color Assessment Cabinet is the smallest Light Box in our range and correspondingly is ideal for smaller product. It should also be considered for offices and production areas where space is at a premium. The smaller size is also reflected in the price.
Core advantages:
The VeviVide CAC60 Color Assessment Cabinet can accommodate up to 4 light sources. (The CAC 60-5 will take up to 5 and is pictured right). The light sources can be specified by you, to meet your own specific needs and requirements. A typical cabinet includes UV and F with a choice of two other light sources - usually D65 and one 'point of sale' light source such as 840, 830 or Cool White. If required A or H can be supplied instead of F.
You can stipulate the voltage you require and can also ask for the cabinet to be fitted with a Diffuser and or Dimmers(dependent upon lamp options you select). The cabinets are normally supplied painted with a neutral matt grey -Munsell N5 but can also be supplied with alternatives of paint colours, Munsell N7or Ref G5574 if required to comply with a particular customer specification.
Applicable Standards:
ASTM D1729, SAE J361, Tappi 7515, BS 950 Part A, AS 1580.6001.1
Specifications:
Overall dimension: 420mm*710mm*545mm(L×W×H)
Viewing area dimension: 380mm × 680mm × 335mm(L×W×H)
Weight: 25kg
Power: 220V/50Hz
Light source:
1. D65--Artificial Daylight, Color temperature: 6500K, Power: 18W
2. TL84/P15--Europe, Japan, China store light source, Color temperature: 4000K, Power: 18W
3. A--Incandescent lamp, household light source, Color temperature: 2856K, Power: 35W
4. H--Tungsten halogen lamp, household light source, Color temperature: 2300K, Power: 75W
5. UV--Ultra-Violet , Color temperature: 3000K, Power: 18W
Applicable Standards:
ASTM D1729, SAE J361, Tappi 7515, BS 950 Part A, AS 1580.6001.1
Specifications:
Overall dimension: 420mm*710mm*545mm(L×W×H)
Viewing area dimension: 380mm × 680mm × 335mm(L×W×H)
Weight: 25kg
Power: 220V/50Hz
Light source:
1. D65--Artificial Daylight, Color temperature: 6500K, Power: 18W
2. TL84/P15--Europe, Japan, China store light source, Color temperature: 4000K, Power: 18W
3. A--Incandescent lamp, household light source, Color temperature: 2856K, Power: 35W
4. H--Tungsten halogen lamp, household light source, Color temperature: 2300K, Power: 75W
5. UV--Ultra-Violet , Color temperature: 3000K, Power: 18W
Basic configuration:
We also have a selection of accessories specifically designed for our CAC cabinet range including Benches, Workstations and Cupboards. Tables, both Tilting and Fixed Angle, are also available.
We also have a selection of accessories specifically designed for our CAC cabinet range including Benches, Workstations and Cupboards. Tables, both Tilting and Fixed Angle, are also available.
Detail Images:
Our Service :
1.Since 2001, Years' experience of Manufacturing. Cooperation with the world's top testing instrument experts - Gellowen in UK to joinly develop the production of textile testing instrument;
2. Service tenet: quick, decisive, accurate, thoughtful and thorough
3. Service aim: customer satisfaction as the goal
4. Service efficiency:Whether the the instrument failure occurs within or beyond warranty ,our maintenance personnel will give you satisfactory reply within 24 hours.
5. Service principle:Product warranty period 12 months, during the warranty period we will provide free maintenance and replacement of damaged parts for the test equipment caused by the quality problem. For the damaged parts beyond warranty period, we supply the new parts at our margin price. Our technical expert will survey the test equipment at least 3 times a year if the machine is beyond warranty period.
Packaging adn shipping:
1,packing: Packed by solid wooden case;
2,Shipping: Shipping by sea or by air,as you requested.
Company Information :
Qinsun Instruments Co., LTD specialize in the research and development of high quality lab instrument for textile testing industry. Our head office in Shanghai and we provide high quality testing instrument and comprehensive service for textile factory,academic research institute and textile lab worldwide.
♥ Main web site1 //www.qinsun-lab.com/
♥ Main web site2 //www.standard-groups.com/
♥ Social Media and other website as following:
https://www.facebook.com/qinsunlab
https://twitter.com/QinsunMarket
https://www.pinterest.com/qinsuninstrumen/pins/
https://cn.linkedin.com/in/qinsunlab-49a255117/en
Certification :
Our customers:
FAQ:
1,Is your company a trading company or factory?
A:Factory + trade (integration), has 6 years focusing on test instruments field, 6 years
exporting experience.
2,After an order is placed, when to deliver?
A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.
Please be aware that our production lead times depend on specific items and item
quantities.
3,What’s the payment term?
A:T/T,L/C and other payment terms could be negotiated.
4,What's the warranty and after-sales service?
A:12 months warranty. Feedback to you within 24h and help you to repair your problem
controller freely, even it's not from our factory.
5,What the standards do you adopt?
AWe have been adopting the world standards and regulation such as ISO, ASTM, DIN, EN, GB,
BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, and CSA.
6,What about the product' services and quality?
A:Each instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need. And our Main clients : SGS, BV and Intertek.
7,What's the cooperation Process?
A:Inquiry - quotation - communication - order confirming - deposit payment - production -
testing and debugging - balance payment - packing - delivery - customer receiving - after
service.
8,Why choose us?
1, Considerate Service Different countries plugs, manually change the-voltage from 110V to
220V, insurance indicator.
2,Excellent After sale Service:
12 months warranty. Besides, we can help you to repair your problem controller freely, even
it's not from our factory. What you need to do is to send us the controller.
3,Commitment:
We will sign a letter of commitment while we sign the contract, which will improve your
confidence to us.
4,Good Packaging: Simulation Animatronic Customer Triceratops are covered with air bubble
film before put them into the wooden case, which not only has good shock absorption, impact
resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture
corrosion, good transparency etc.
