1500 GPH Auto Submersible Pump

Compact, automatic, fully submersible electric pump
Equipped with built in electronic controlled reed sensor system for easy fully automatic operation
No power use until pump is activated by sensor (when water level rises)
Compact, efficient, long life motor
Rustproof and corrosion resistant
Stainless steel shaft
High-impact durable plastic housing
Quick release strainer for easy maintenance
Extremely efficient, very low current
draw and offer high capacity output
Water cooled long-life motors
Ignition protection to protect the pump against high current
Water/moisture tight seals
Silent and vibrationless operation
Can be used with switch panel for manual override
Includes comprehensive user manual with installation instructions and wiring diagram

Images

Models

Models	Voltage	Current	Fuse	Capacity	Head	Hose ID
169432	12 V	2.9 A	5 A	500 GPH (1890 L/H)	4.2 m	19mm (3/4")
169434	24 V	1.5 A	3 A	500 GPH (1890 L/H)	4.2 m	19mm (3/4")
169442	12 V	4.2 A	6 A	700 GPH (2646 L/H)	4.5 m	19mm (3/4")
169444	24 V	2.2 A	5 A	700 GPH (2646 L/H)	4.5 m	19mm (3/4")
169462	12 V	6 A	10 A	1500 GPH (5670 L/H)	2.9 m	28.575mm (1 1/8")
169464	24 V	3.1 A	5 A	1500 GPH (5670 L/H)	2.9 m	28.575mm (1 1/8")
169472	12 V	7.8 A	12 A	1800 GPH (6800 L/H)	3.5 m	28.575mm (1 1/8")
169474	24 V	4 A	8 A	1800 GPH (6800 L/H)	3.5 m	28.575mm (1 1/8")
169482	12 V	9.5 A	15 A	2000 GPH (7560 L/H)	4 m	28.575mm (1 1/8")
169484	24 V	4.8 A	9 A	2000 GPH (7560 L/H)	4 m	28.575mm (1 1/8")

Packing & Delivery

500 GPH & 700 GPH Pumps

36 PCS/ Carton

N.W. : 16.8 KGS
G.W. : 17.2 KGS
MEASURE : 38cm X 36cm X 38cm

1500 GPH, 1800 GPH & 2000 GPH

12PCS/Carton
N.W. : 13.0 KGS
G.W. : 13.6 KGS
MEASURE : 42cm X 30cm X 32cm
