Using bobbin dyeing factory soft Polyester/nylon yarn winding machine textile machinery factory
- Category: >>>
- Supplier: Jiangsu Tangshi Textile Machinery Group Co. Ltd.
Share on (60558338396):
Product Overview
Description
Product Description
Using bobbin dyeing factory soft Polyester/nylon yarn winding machine textile machinery factory
Please click here to view more products
Bobbin type | 5"(170mm) | ||
Layout | Double-side, can be 12-96 spindles | ||
Power Supply | Three phases 380V 50/60HZ | ||
Driving | Every spindle per motor | ||
Power Comsumption | 0.09KW/spindle | ||
Take-up package | Tube Bobbin (0°) / Cone 4°20, 5°57, 9°15 | ||
Package Diameter | Max.250mm | ||
Yarn tension and waxing device | Every spindle has a yarn tension | ||
Auto Stop Device | Each spindle install auto stop device | ||
Traverse Device | Mechanical Traverse suit for soft winding | ||
Cleaner device | Every spindle has a Mechanical Knife yarn cleaner | ||
Electronic Yarn Cleaner | Optional installed | ||
Air Splicer | Optional installed | ||
Blower cleaner | Optional installed | ||
Lighting System | contain | ||
Dimensions | L 11850 x W 1080 x H 1500 mm | ||
Parameters:
1. Drive: every spindle per motor
2. Winding speed: Cotton: about 800M/min, Fiber: about 600 M/min
3. Has function of Anti-Hard-Edge and Electronic Anti-Stack.
4. Package Dia≤ 220mm; Take-up length: 152mm.
5. Each spindle with length counter.
6. Advanced control panel.Drum
TS008S High Speed Soft winding machine, it's mainly for the Yarn Dyeing preparing
using, suit for winding like Fiber yarns, Cotton yarns, FDY, Polyester yarns and etc, and it
can take up with Conical Cone or Tube bobbins. It has the feature of High Efficiency and
well take-up finished shape, can alleviate the intensity of labour for next processing work.
FAQ
Q: What is the real winding speed for this machine
A: It's depends on how the performance and take up package formed, if the take up package formed well, then you can increase the speed, normal winding machine is 600-800m/min
Q: My bobbin is some kind of special, is that workable on the machine?
A: We will make the spindle head base on the bobbin that customer provide.
Q: The yarn always break, how to solve it?
A: 1. Check the tension first, if the tension is too big, just reduce some weight
2.Check the yarn whether it's in the right path.
3.Check the quality of yarn, sometimes yarn breakage due to the weak yarn
Q: How to solve the problem if the package become too hard and start bounce?
A: Try to reduce the tension or speed
Q: Does your machine shake when full load running?
A: No, our machine frame is very strong, it's quite stable
Comparison
Packaging & Shipping
Packaging&Shipping
Before loading,the machines are covered with waterproof plastic first,then packed in solid wooden case.
Company Information
Jiangsu Tangshi Textile Machinery Group Co., Ltd was an experienced and professional manufacturer, it already has 30 years' experience of producing drum winding machines, with advanced technics and production equipments it can output more one thousand winding machines annually. after these years hard work and faith cooperation, Jiangsu Tangshi Textile Group Co., Ltd got a good reputation. our products like GA014 series soft and tight winding machine, TS008 semi-automatic soft and tight winding machine, TS230,280,290,300 big take-up winding machine. and we also can customize machines according to the customers' special demands. we service the textile industry in conformance with the aim of “professional produce, faith operation, reputation brand ”. The products are widely sold at domestic and also export to south-east asia countries gradually.To supply all kinds of winding machine is our company's feature, good quality and in time deliverly is our promise. sincerely hope we can go forward hand in hand and set up bright life together!Winding machine------------Jiangsu Tangshi Textile Machienry Group Co., Ltd will be your best choose!
