Aater-cooled Box Type Industrial Water Chiller (-7℃).
working condition of refrigeration:
1.Frozen ethylene glycol Cold water inlet temperature -1℃, outlet water temperature -5℃,ambient temperature 35℃.
2.This series machine is applied in low temperature condition, must use 25% ethylene glycol, 20% calcium chloride such as antifreeze as refrigerant.
3.This series unit uses fully enclosed compressor imported from Europe and the United States, superior performance, strong anti-strike liquid capability .
4.Power supply: three-phase four-wire system 380V/220V 50HZ
Product Feature:
1. Using the international most advanced scroll compressor or piston compressor
2.Using the world famous brand refrigeration components
3.Electric control components, all using domestic and international famous brand products
4.Without foundation installation, simple operation.
Technical Specifications
Item
Cooling Capacity
Total Power
Chilled Water Flow (m3/h)
Pipe
L
W
H
N.W
KW
KCal/h
KW
mm
mm
mm
KG
SCLF-3-C-X
7.5
6500
2.9
1.3
DN25
940
750
1330
140
SCLF-5-C-X
12.5
10700
4.5
2.1
DN25
960
750
1370
210
SCLF-7-C-X
18.5
15900
6.4
3.2
DN25
1300
850
1530
300
SCLF-10-C-X
28.5
24400
9
4.9
DN40
1460
850
1530
300
SCLF-12-C-X
33
28400
10.9
5.7
DN40
1560
850
1530
360
SCLF-15-C-X
41.5
35800
13.6
7.2
DN40
1700
1000
1620
650
SCLF-20-C-X
57
49000
18.3
9.8
DN50
1950
1150
1790
750
SCLF-25-C-X
70.8
60900
24.7
12.2
DN50
2100
1250
1610
1050
SCLF-30-C--S-X
83.2
71500
25.7
14.3
DN65
2200
1250
1880
1250
SCLF-40-C--S-X
114
98000
35.3
19.6
DN65
2450
1350
1960
1350
Our Service
(1). Pre-service
A:24 Hours online service
B:Our prefessional sales will help choosing the right products for you
2. Middle service
A:Try to give you our best offer
B:Costomized products as your requirment
C:Discuss the payment term as your convienent.
D:Talking about the delivery and packing
E:Can provide invoice value as you like to decrease your tax.
3. After sale service
A:1 year warranty service after the equipment debugging.
B:Technical Egineer are avalible for oversea trainning.
C:Free change for some parts
D:Free installation DVD
E:Maintenance plan
Packaging & Shipping
Company Information
Established in 1997, Hangzhou Shanli Purify Equipment Corporation is an enterprise specialized in design, development and production of compressed air dryers, filters and other purification equipments.
Our company has a workshop of 30, 000 square meters and more than 300 staff. Shanli has become one
of the largest manufacturers in the Chinese purification industry with the top sales turnover. Our self-design and self-made equipment is compatible with many famous brands of air compressor to efficiently remove water, oil and dust from
compressed air. On basis of IS0 9001 certification standard, our design, production, test and services of the machine are
all well- managed and strictly controlled since year 2001.
FAQ
1 Business Type ♦ Factory located in Hangzhou ♦ Factory covers an area of 40,000m² ♦ Employees,over 300 people
2 What are your main products? ♦ Refrigerated air dryer ♦ Adsorption air dryer ♦ Combined refrigerated and adsorption air dryer
♦ Water chiller
♦ Water chiller
♦ Oil filter
♦ Dust filter 3 How to make order? ♦ Communicate with our salesman ♦ Provide your customized technical parameters ♦ Offer you a price as your requirement ♦ Payment term,shipping packing ♦ Start the bulk production after receiving your deposit ♦ Forwarder books the cargo
♦ Delivery the goods and balanced after receiving the copy of B/L ♦ Welcome your second order and further more orders in future
4 Quality Assurance ♦ 100% inspection before shipment
5 Why choose us?
♦ With more than 20 years experiences in compressed air dryer
♦ Shanli is the leading brand in China ♦ Professional engineers and workers ♦ Experienced OEM service made to customer specifications ♦ Dedicated customer service and technical support
