Complete CSD Carbonated Soft Drink Production Line / Filling Bottling MachineShare on (60559896828):


This Carbonated three-in-one machine for PET bottle integrates the function of rinsing, filling and capping together. Based on advanced technology overseas, and designed according to carbonated filling processing demands
Characteristic:
1. This machine has a compact structure, completed control system, easy to operate and highly automated.
2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.
3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.
4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
5. The machine adopts high effective cap sorting system and completely self control and protective device.
6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
8. The electric components and pneumatic components are all introduced from world famous brand products.
Parameter:
Model | DCGF 16-12-6 |
Amount of working position | Rinsing 16, filling 12, capping 6 |
Production capacity | 3000-4000BPH |
Filling pressure | 0.15-0.4Mpa |
Rinsing water pressure | 0.2-0.25Mpa |
Rinsing water capacity | 0.3T/H |
Main motor power | 2.5kW |
Total power | 4.4KW |
Dimension | 2250X1650X2250m(L×W×H) |
weight | 2500kg |
Technological Flow Sheet (Carbonated Drink Production Line):
1. PET Preform Injection Molding System
PET material→ Dehumidify→ Load material→ Injection machine→ Preform
2. PE/PP Cap Compression Molding System
PE material→ Dehumidify→ Load material→ Compression machine→ Cap
3. PET Bottle Blowing System
PET Preforms→ heat preform→ stretch→ blowing→ bottles
4. Water Purifying System
Raw water→ Multistage centrifugal stainless pump→ Quartz sand filter→ Active carbon filter→ Water softner→ Micro filter→ Reverse osmosis→ UV sterilizer→ Water tank→ Pump
5. Carbonated Beverage Preparing System
Sugar melting tank→ Pump→ Syrup filter→ Mixing tank→ Pump→ Syrup cooler→ Carbonated Mixer←Cooling water tank← Chiller
CO2 filter
6. Filling, Labeling and Packing System
(Bottle Unscramble)→ Air conveyor→ Rinsing, Filling& Capping Mono-Block→ Lamp checker→ Conveyor→ Bottle Warmer→ Dryer→ Auto labeling machine→ Date printer→ Auto PE Film pack shrinking machine/Carton packing machine→ Stock



Zhangjiagang Evertop Machinery Co., Ltd., which has the function of research, development and manufacture, is specialized in beverage packaging machinery.
We are providing the following products: liquid filling machine (bottle water, juice/tea, carbonated drink, oil, milk, wine etc.), 3 to 5 gallons water filling production line, water treatment machine, labeling and packing machine, automatic/semi-automatic bottle blow molding machine, injection molding machine and automatic batching, mixing system, a variety of sterilization equipment etc.
Since foundation, we devote all the strength to the new field of beverage packaging machine technology and absorb the advanced technology from German and Italy. Company insists the management ideas of market-oriented, technology-first, quality of life, faith-based, service paramount, and has established perfect quality assurance system.
1. The plant layout
To provide customers with pre-project workshop planning, design.
2. Commissioning services
Send experienced engineers and technicians to be responsible for equipment installation and commissioning, to ensure customers' factory normal production.
3. Spare parts
With one year of wearing parts when the device is shipped. In addition, we prepare adequate equipment spare parts in stock. Customers ever need spare parts to repair and maintain quipment, we can supply to them quickly.
4. Technical training
To ensure that your technical staff to become familiar with the performance of the equipment, to master the equipment proper operation and maintenance procedures, we provide on-site technical training, in order to facilitate customers faster and more comprehensive access to technology.
Q What is your trade clause?
A We mainly handle it by FOB, CFR, CIF, EXW, FCA. It depends on the client’s need.
Q What is your payment term?
A 30% by T/T in advance as deposit, balance 70% by T/T or irrevocable L/C at sight before shipment
Q What is the valid of your price?
A Because the cost and exchange rate changes rapidly, so all of our quotation for you is with 30 days valid. If you need any update price, please feel free to contact us.
Q How could I know if your products' specification is suit for our country power?
A All the machines are custom made. We will make suitable voltage and frequency products according to your need.
Q How long can you arrange delivery?
A About 30 days after we received the deposit payment, all the machines will be ready. You are welcomed to test the machine in my factory or we send you video of your machine running. Then you arrange the balance payment and we will pack the machines with wooden case and arrange the shippment by sea or by train.
