lab sample preparation equipment metallographic specimen automatic cutting machine
Product Description
Introduction:
Q-80Z type cutting machine can cut round specimens of the diameter within 80mm, also can cut witin height 80mm, depth 160mm rectangular specimens. The machine through automatic cooling systemto cool the sample, to prevent the sample overheating and burning during the cutting process. The cutting machine can also set the cutting speeds due to different samples, so as to improve the quality of cutting samples. The machine has manual cutting and automatic cutting types. With large cutting chamber and easy cutting for user, the cutting machine is one of metallographic test necessary sample preparation equipments for the colleges, factory enterprices. lab sample preparation equipment metallographic specimen automatic cutting machine
Technical specifications:
1. Power: 380V, 50Hz
2. Spindle speed: 2200r/min
3. Grinding wheel size: 350*2.5*32mm
4. Max. cutting ability: φ80mm,
Automatic cutting speed: 0.1-3.0mm/min,
It can choose automatic cutting way: interval cutting(big and hard workpiece), continuously cutting(small and soft workpiece)
Attension: the “Max. cutting ability” refers to new cutting wheel’s cutting ability, the actual cutting ability depends on specimen’s materials, grinding sheet and clamping technics.
5. Max. cutting capacity: 100*200mm
6. Motor: Three phases, 380V, 50Hz, 3kW
7. Cutting table size: 300*290mm
8. Dimension: 850*880*1200mm
Company Information
Liangong Group, a well-known enterprise in testing machines industry as well as a state-level high-tech enterprise which specialized in R & D production and sales fo testing equipment for metal and nonmetal materials. Liangong Group include Jinan Liangong Testing Technology Co., Ltd, Shandong Liangong Testing Machine Co., Ltd, ASTM Testing Equipment Co.,Ltd. Our company covers an area of 30,000 square meters, construction area of 10,000 square meter, with a total investment of 80 million yuan. Our company has a well experienced, strong and large-scale R & D team and is based on high-quality technical personnel. By means of advanced science and technology, strong production capacity and financial support, we cooperate with many domestic and foreign well-known educational institutions and research institutions closely to make our company be in domestic leading position in research and development of new products.
Our service objective: reliable quality, Credit and Reputation First, and service in time!
We promise to provide each customer with timely, efficient and high-quality service!
www.lgtester.com www.jnliangong.com www.testermachine.com
https://youtu.be/eV36YIy20fY
LIANGONG GROUP:
CUSTOMER VISITS AND INSTALLATION & TRAINING AT SITE
Our main Products
Our main products are materials testing machine, inclduing broaching machine, temperature champer, impact tester, bending testing machine, compression testing machine, universal testing machine, hardness tester, cupping testing machine, metallographic machines. and other OEM customized testing machine etc.
