Product Overview

Description


GCS Overrunning Clutch Roller Type Bearing

Product Description

_08 Feature

Type "GCS" is a roller type plectrum overrunning clutch with bearing supported.



Data Sheet

ItemGCS
MaterialGCr15
Inner dia.25-70 mm
Outer dia.76-225 mm
Thickness54-135 mm
Weight1.1-26.52 kg
Torque49-2819 Nm
Overrunning speed(inner race)266-1000 r/min
Overrunning speed(outer race)168-595 r/min
PackageSinger package or as your reuirements
Delivery time15-20 days



Different Sizes For Your Reference


ModelTorqueOverrunning Speed (r/min)Dimensions (mm)Weight
NmOuter raceInner racedD1DLL1NbxtHkg
GCS25764959510002564765424.5M68x3.3151.1
GCS3086605258503074865526M810x3.3161.5
GCS35961004107203584966830M810x3.3163.07
GCS4011016038668440951108038M1012x3.3184.68
GCS45125246346630451121258542M1012x3.3185.65
GCS50140380335605501201409650M1214x3.8207.63
GCS551606132905055514016010856M1414x3.82010.5
GCS6018011752504236015618012065M1416x4.32017.89
GCS6520015102233606516420013065M1616x4.32020.15
GCS7022528191682667018022513570M1818x4.42026.52
Detailed Image

GCS-DETAIL



Packaging

2packing

Company Information

3our company

4production-process_03

FAQ

5RFQ

FAQ .jpg
