Абразивная ленточная машина для склеивания с автоматическим склеиванием

Product Application

The skiving machine type LONG VERSION is produced to process paper and cloth narrow belts. Even though ideal for narrow belts, the machine can be equipped to work with wide belts. The LONG VERSION is indicated for converters with medium-high productions.Abrasive belt skiving machine with auto gluing

Main Features

1) Simple structure ,easy in installation and maintation.

2) Adopting advanced famous brand components in pneumatic parts ,electric parts and operation parts.

3) High pressure to control the die opening and closing.

4) Running in a high automatization and intellectualization,no pollution

Abrasive belt skiving machine with auto gluing

Abrasive belt skiving machine

Name: skiving machine

Brand: WOKING

Original: China

skiving/grinding width:No limitation

Working speed:30-200mm/s(adjustable)

Pressure device:Pneumatic

Air pressure:0.7 MPa

Installed power:10 KW

Total weight:1.5 Tons

Abrasive belt slitting machine

Name:Belt slitting machine
Brand: WOKING
Original: CHINA
Cutting surface width:10mm-650mm

Cutting length:\t530mm-4000mm

Setting Pressure:500Kgf

Cutting precision:± 0.5mm

Installed power:2.2 KW

Package:Packed in wooden case 1*1*1.02M

Abrasive belt joint press machine

Name: Joint press machine
Brand: WOKING
Original: CHINA
Max working surface width:450mm

Working Temperature:Temperature can be adjustable

Press time:1-99 seconds/belt adjustable

Press pressure:15T

Installed power:4 KW

Package:Packed in wooden case 1.36*1.05*1.85M

Linear joint wide abrasive cloth cutting machine

Name: Joint wide abrasive cloth cutting machine
Brand: WOKING
Original: CHINA

Cutting surface width:0-1650mm/2050mm

Air pressure:0.75Mpa

Cutting method:Reciprocating rolling

Cutting precision:0.75 KW

Package:Packed in wooden case 2.9*1.6*0.8M
