Product Overview
Description
Single Aluminum Extrusion Billet Heating Furnace
Single Aluminum Extrusion Billet Heating Furnace Parameters:
| Billet dia. | 4inch | 5inch | 6inch | 7inch | 8inch | 9inch | 10inch | 11inch | 12inch | 13inch | 14inch |
| Press | 800T | 1000T | 1400T | 1800T | 2000T | 2500T | 3000T | 3600T | 3600T | 4500T | 4500T |
| Billet Length | 6~8m | ||||||||||
| Max.temp. | 538 degree | ||||||||||
| Temp.tolerance | +-5 degree | ||||||||||
| Heat up time | 20min | 20min | 25min | 25min | 30min | 35min | 35min | 40min | 40min | 50~60min | 50~60min |
| heat area | 3 | 3 | 3 | 4 | 4 | 4 | 5 | 6 | 6 | 6 | 6 |
| Natural gas consumption | 20m3/T | 20m3/T | 25m3/T | 25m3/T | 25m3/T | 28m3/T | 28m3/T | 28m3/T | 28m3/T | 28m3/T | 28m3/T |
| Fuel | Natural gas/LPG | ||||||||||
| Compressed air | 5~8Bar | ||||||||||
| combustion fan | 5.5kw | 5.5kw | 7.5kw | 7.5kw | 15kw | 15kw | 15kw | 15kw | 15kw | 15kw | 15kw |
| circulation fan | 7.5kw | 11kw | 11kw | 15kw | 18.5kw | 18.5kw | 18.5kw | 30kw | 30kw | 30kw | 30kw |
| power | 15kw | 18.5kw | 18.5kw | 24.5kw | 35.5kw | 35.5kw | 47kw | 47kw | 57kw | 47kw | 47kw |
