Product Overview

Description


                       GECEN Universal Ku band Fuji Single LNB  Model






Product Description


GKF-2172 02GKF-2172 03GKF-2172 0GKF-2172 04







 Features:



  • Low noise figure

  • Digital ready

  • Low power consumption

  • Easy installation

  • High quality weather protection










Specifications










































































Item






Specification






I


tem



Specification


Input Frequency RangeLow Band:10.70~11.70GHz
High Band:11.70~12.75GHz		L.O. Phase Noise-50dBc/Hz@1KHz
-75dBc/Hz@10KHz
-95dBc/Hz@100KHz
Output Frequency RangeLow Band:950~1950MHz
High Band:1100~2150MHz		Image Rejection40dB(Min.)
Noise FigureLow Band:0.6dB(Typ.)
High Band:0.6dB(Typ.)		Output VSWR2.0:1(Max.)
Conversion Gain60dB(Typ.)Output Power

0dBm (Min.)(at 1dB gain
compression)


Gain Flatness±0.5dB/26MHzConnector Type75Ω Female Connector
Cross POL. Isolation25dB(Typ.)DC Current Consumption80mA(Typ.)
L.O. FrequencyLow Band:9.75GHz
High Band:10.60GHz		Low/High Band SwitchingLow Band:0Hz
High Band:22KHz±4KHz
L.O. Frequency Stability±1.0MHz (Max.)@+25°C
±2.0 MHz (Max.)@-30°C~+70°C		POL. Switching Voltage10.5~14.0V @VP
16.0~20.0V @HP
 Operating Temperature -30°C~+70°C






Packaging & Shipping







Our Services













Company Information
























FAQ



Q1. Can I get some samples beore mass prduction?
A: Yes, samples can be offered for testing.



Q2. What is the delivery time?


A:30-35days






Q3. OEM can be supported?


A: Yes, OEM can be support. Package, specification can be supported.






Q4: What is the guarantee for the products?


A: One year.
