HVAC U Shape Air Duct Auto Production Line V For Square Steel Ventilation Pipe

It is mainly used for forming TDF/angle steel flange or C-type flange. Daily processing capacity 1000-2500 square meters. As long as the size of the air duct is input and the production line automatically completes the uncoiling, leveling, beading, punching, shearing, locking, TDF/angle steel flange forming or C-type flange forming and folding forming.

1. U-shaped structure, small area, simple assembly, suitable for small and medium-sized factories

2. Servo pneumatic manipulator drives feeding to ensure smooth, accurate positioning and faster speed.

3. Super high efficiency, super labor saving, each L piece only takes 20-25 seconds, the efficiency is twice as high as that of straight line type.

4. Fixed locking machine, saving time of moving back and forth, improving work efficiency

5. All rollers are made of bearing steel, and their service life is increased by more than 5 times.

6. The CNC system adds material-saving mode, with only one piece of waste less than 20mm per roll.

7. With production memory function, it can query production orders.

Major Import Configuration

1. Beijing Huade+Taiwan Hydraulic System

2. Germany Siemens system

3. Taiwan HIWIN Linear Guideway

4. Schneider Electrical System

Basic configuration

1. Electric coiling rack with 4 material tray (5-7 tons per coil)

2. One bracket

3. One mainframe (second-line mainframe)

4. Two stainless steel drum conveyor platforms

5. 1 Set Fixed joint locking machine

6. A Two-machine Linkage TDF flange forming machine

7. A Two-machine Linkage angle steel flange forming machine

8. A servo feeding platform

9. A hydraulic folding machine

10. 1 Set of computer control system
