  • Constant Current 0/1 10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1 10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light
Constant Current 0/1-10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light

Constant Current 0/1 10V dimmable 100 watt led driver with electronic waterproof led light dimming outdoor street light

Share on (60570475722):


Price:$14.60 - $15.50

Quantity:


Product Overview

Description


 Constant Current 0/1-10V dimmable 100 200 watt led driver with electronic waterproof led light  dimming outdoor street light



Product Description





















Why choose us?















Product List





constant voltage LED driver , LED power supply

























































































































































































































































































































Model NumberInput Voltage

Output Voltage


(for choice)



Output Current


(for choice)


Output Power
MSD-CV-20WAC 85-265VDC 12V1.67A20W
DC 24V0.83A
DC 36V0.55A
MSD-CV-30W

AC 85-265V



DC 12V



2.5A


30W








DC 24V



1.25A



DC 36V



0.83A


MSD-CV-40WAC 85-265VDC 12V3.33A40W
DC 24V1.67A
DC 36V1.11A
MSD-CV-50WAC 85-265VDC 12V4.17A50W
DC 24V2.08A

DC 36V



1.39A


MSD-CV-60W

AC 85-265V



DC 12V



5A


60W

DV 24V



2.5A


DC 36V1.67A
MSD-CV-70W

AC85-265V



DC 12V



5.83A


70W

DC 24V



2.91A



DC 36V



1.94A


MSD-CV-80WAC85-265V

DC 12V



6.67A


80W
DC 24V3.33A

DC 36V



2.22A


MSD-CV-90WAC85-265V

DC 12V



7.5A


90W

DC 24V



3.75A



DC 36V



2.5A


MSD-CV-100WAC85-265V

DC 12V



8.33A


100W

DC 24V



4.17A



DC 36V



2.8A


MSD-CV-120WAC85-265V

DC 12V



10A


120W

DC 24V



5A



DC 36V



3.33A


MSD-CV-150WAC85-265V

DC 12V



12.5A


150W

DC 24V



6.25A



DC 36V



4.17A


MSD-CV-160WAC85-265V

DC 12V



13.3A


160W

DC 24V



6.5A



DC 36V



4.4A


MSD-CV-180WAC85-265V

DC 12V



15A


180W

DC 24V



7.5A



DC 36V



5A


MSD-CV-200WAC85-265V

DC 12V



16A


200W

DC 24V



8.33A



DC 36V



5.56A



DC 48V



4.17A


MSD-CV-240WAC85-265V

DC 12V



20A


240W
DC 24V10A
DC 36V6.67A
DC 48V5A
MSD-CV-250WAC85-265VDC 12V20.83A250W
DC 24V10.4A
DC 36V7A
DC 48V5.2A
MSD-CV-300WAC85-265VDC 12V25A300W
DC 24V12.5A
DC 36V8.3A
DC 48V6.25A
MSD-CV-350W

AC85-265V



DC 24V



14.6A


350W

DC 36V


9.7A

DC 48V


7.29A
MSD-CV-400W

AC85-265V



 DC 24V



16.6A


400W

 DC 36V


11.1A
 DC 48V8.33A



- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -  - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -


constant current LED driver , LED power supply


















































































































































































































































































































































































































































































































































Model numberInput VoltageOutput VoltageOutput CurrentOutput Power
MSD-CC-20WAC 85-265VDC 28-36V600mA20W
DC 14-22V900mA
DC 13-19V1050mA
MSD-CC-30W

AC 85-265V



DC 33-43V



700mA


30W

DC 28-36V



900mA



DC 24-32V



900mA


DC 20-28V1200mA
DC 18-25V1200mA
DC 20-28V1050mA
DC 12-20V1500mA
DC 12-18V1800mA
MSD-CC-40W

AC 85-265V



DC 15-20V



2000mA


40W
DC 15-22V1800mA
DC 20-26V1500mA
DC 26-33V1200mA

DC 28-36V



1200mA



DC 35-42V



900mA



DC 40-48V



850mA


MSD-CC-45W

AC85-265V



DC 85-130V



350mA


45W

DC 45-65V



700mA


DC 28-43V1050mA
DC 32-40V900mA
DC 29-37V1200mA
DC 22-30V1500mA
MSD-CC-50WAC85-265V

DC 15-24V



2400mA


50W
DC 18-25V2100mA
DC 20-28V1800mA
DC 28-36V1500mA
DC 35-42V1200mA
DC 45-60V900mA
MSD-CC-60WAC85-265V

DC 20-28V



2100mA


90W

DC 28-36V



1800mA


DC 30-42V1400mA
DC 35-42V1500mA

DC 40-52V



1200mA



DC 48-57V



1050mA



DC 60-72V



900mA


MSD-CC-70WAC85-265V

DC 28-36V



2100mA


70W
DC 35-42V1800mA
DC 40-52V1500mA
DC 21-30V2400mA

DC 18-24V



3000mA



DC 12-21V



3500mA


MSD-CC-80WAC85-265V

DC 20-28V



3000mA


80W
DC 28-36V2400mA
DC 35-42V2100mA
DC 40-52V1800mA
DC 45-60V1500mA

DC 60-72V



1200mA


MSD-CC-90WAC85-265V

DC 50-60V



1500mA


90W

DC 40-50V



1800mA


DC 35-45V2000mA
DC 27-37V2400mA
DC 23-33V2700mA
MSD-CC-100WAC85-265V

DC 12-20V



4800mA


100W
DC 28-36V3000mA
DC 35-42V2400mA
DC 45-60V1800mA
DC 60-72V1500mA
DC 90-110V900mA
MSD-CC-120WAC85-265V

DC 15-24V



5400mA


120W
DC 20-28V4500mA
DC 28-36V3600mA

DC 35-42V



3000mA



DC 40-52V



2400mA



DC 45-60V



2100mA


MSD-CC-140WAC85-265V

DC 80-93V



1500mA


140W

DC 48-58V



2400mA


DC 36-46V3000mA
DC 30-39V3600mA
DC 25-35V4000mA

DC 23-33V



4200mA


MSD-CC-150WAC85-265V

DC 28-36V



4500mA


150W
DC 28-36V4200mA
DC 35-42V3600mA
DC 40-52V3000mA
DC 40-54V3000mA
MSD-CC-160WAC85-265VDC 60-72V2100mA160W
DC 60-72V2400mA
DC 90-110V1500mA
MSD-CC-180WAC85-265VDC 28-36V5400mA180W
DC 35-42V4500mA
DC 40-52V3600mA
DC 50-65V3000mA
DC 60-72V2700mA
DC 90-110V1800mA
MSD-CC-200W

AC85-265V



DC 20-28V



7500mA


200W
DC 28-36V6000mA
DC 35-42V4800mA
DC 40-52V4200mA
DC 45-60V3600mA

DC 60-72V


3000mA
MSD-CC-240W

AC85-265V



DC 20-28V



9000mA


240W
DC 28-36V7200mA
DC 35-42V6000mA

DC 40-52V


4800mA

DC 60-72V


3600mA
DC 75-90V3000mA
DC 90-110V2400mA
MSD-CC-250WAC85-265VDC 75-85V3000mA250W
DC 30-36V7000mA
MSD-CC-280WAC85-265VDC 85-95V3000mA280W
MSD-CC-300WAC85-265VDC 20-28V12000mA300W
DC 28-36V9000mA
DC 40-52V6000mA
DC 50-60V5000mA
DC 60-72V4500mA
DC 90-110V3000mA
MSD-CC-400WAC 85-265VDC 30-36V11000mA400W
DC 57-65V6100mA
DC 57-68V5800mA
DC 60-72V5500mA
DC 63-76V5200mA





certificate


.jpg





Packaging & Shipping


++


Samples checking: sending by Express (DHL / UPS / FEDEX / TNT/EMS)


Bulk production: sending out by cargo shipping / air freight / Express








Trade Shows





 2





FAQ


1. Are you a factory or a trade company?


    We have been professional muafacturer of  LED drivers for 8 years.


    OEM &ODM is available, such as watts, output current/voltage, length/plug of cable, label...





2. Do you have MOQ requirement?


    No MOQ. We would like to offer samples for customer to test first.





3. Shipping time


    We always have materials in Stock, the delivery time is very short.
    Regarding to the samples, we have samples and materials in stock..


    Samples:1-3 days, big order:5-10days





4. Service


     We have a professional service team to solve all the questions and problems. No worry about the after-sales service.





5. How about your R&D capability?


     We have professional engineers for cetificates and research&development. Recently, we have passed SAA TUV and updated DALI LED driver series.





6. Can I  buy the products with my own logo?


     Sure. OEM/ODM is available.





7. Is there any discount for large qty?


    We provide discount based on the qty and can also bear the freight cost.
