rtv2 silicone for pad printing cheap price liquid silicone rubber make silicone print pad head

Product Overview

Description



rtv2 silicone for pad printing cheap price liquid silicone rubber make print pad





Product Features:
1. Low viscosity, good fluidity
2. Non-toxic and odorless
3. Silicone color, hardness, operating time, curing time and other adjustable
4. Easy to mold after curing, low shrinkage
5. Anti-tearing effect after curing





Datasheet:

Type	Color	Mix ratio	Viscosity (cps)	Tear strength (kgf/cm2)	Tensile strength (kgf/cm2)	Elongation (%)	Pot life (min)	cure time (h)	Shrinkage (%)
HL-390	white (custom)	100:2	8000±1000	≥25	≥60	500-600	20-30	2-3	≤0.1





Application:

rtv2 silicone for pad printing mainly used for plastic pad, electroplating products, electronic toys, trademarks, communication equipment, craft gift stationery and other irregular pattern printing printing pad, the principle is the pattern on the steel plate as the carrier, Of the pattern is transferred to the product.







Introduction:

rtv2 silicone for pad printing with room temperature vulcanization and heating fast curing type, before curing is based on A, B components of the flow of liquid separation, at room temperature curing molding, specifically for the production of printing plastic head, with excellent resistance Grinding, deformation, do not take the oil and a good ink transfer performance. The curing time of silica gel varies with the amount of curing agent added, the more the amount of curing agent added, the faster curing. Silicone printing pad can be prepared with excellent performance of the printing elastic materials, products with low viscosity, good mobility, easy to mold products, no shrinkage, no oil, deformation and other characteristics of the printing pad. Finished pad printing with good ink transfer properties and oil resistance solvent.





Condensation type operate method:
1,first clean the mold with detergent, clean the mold of the water dry or dry with an air gun, and coated with a layer of release agent or Vaseline
2, the AB component in accordance with the weight ratio of 100: 2 mixing evenly (using electronically more accurate)
3, the need to add silicone oil, the first A silicone and silicone oil in accordance with the ratio of 10: 3 (silicone oil added according to customer requirements may be, should not add too much) Silicone and silicone oil mixing evenly, according to the proportion of 100: 2by adding B curing Mix again and stir well.
4, the silica gel will be placed evenly vacuum in addition to vacuum in the bubble (no bubbles can be filled with silicone containers do not need to fill, so as not to vacuum when the silicone overflow container)
5, the vacuum is completed, the mold will be poured into the mold to wait for room temperature (room temperature for 2-12 hours to fully cure)
6, will be completely cured silicone can be stripped





rtv2 silicone for pad printing complies with ROHS environmental protection requirements, by the European Union LFGB food inspection product certification.





A/B series standard packing is 1 kg / 5 kg / 20 kg / 25 kg / 200 kg/barrel.

 Shelf-life:     12 months.





Storage and shipping:

factory price pad printing liquid silicon should be kept sealed in ventilation, cool, dry place, away from the children's place, prevent sun direct illuminate, does not belong to dangerous goods, according to the transport of dangerous goods.



Loading shippment





Shipping



Our company provide mold technology, If there is any quality problem return within three months.









Dongguan hong lian organic silicon technology co., LTD. Is engaged in the organic silicon materials research and development, production, sales and service as one integrated organic silicon materials science and technology enterprises, the company in the process of production, continue to carry out independent innovation activities,Dongguan hong lian organic silicon Dongguan hong lian organic silicon products absolutely conforms to the USA CFR21. Part. 177.2600 and European EN14350-2 in section 4.9 can be volatile compound test standard and the European ROHS standards.
