Машина для прессования угольных порошков/машина для производства барбекю/машина для прессования угольных шаров

Product Overview

Description

Charcoal coal powder ball pressing machine/BBQ making machine/coal ball press machine



 Technical parameters for coal charcoal powder pressing machine

Model	UDGY-290
Roller diameter(mm)	290
Capacity (t/h)	2
Motor power(kw)	5.5
Dimension(cm)	100*140*140
weight(kg)	700



Features

big forming pressure, adjustable rotate speed, with a screw feeding device.

Pressure ball machine consists of three parts: feeding part; transmission part; molding part.
feeding part, mainly to achieve quantitative feed to ensure uniform access to the material between the roller. Screw feeding device driven by the electromagnetic speed motor, the pulley, worm reducer rotation, the pressure will be forced into the main feed material into the mouth. Due to the constant torque characteristics of the electromagnet timing motor, when the feeding volume of the screw feeder is equal to the required material amount of the host machine, the constant feeding pressure can be maintained to stabilize the pellet mass. Such as the feed volume is too large, the feed device of the electrical overload; feed volume is too small is not a ball. Therefore, skilled operation of the technology is to ensure that the work of pressure ball important conditions.
