Product name :

LK2678BX Ground Resistance Tester

Model :

LK2678BX

Dimension:

350mm x 130mm x 275mm

Quantity:

1 set

Technical Parameters:

1.

Testing range:

0~200mΩ(15A)    0~600mΩ(10A)

2.

accuracy:

±5% / ±5%

3.

Voltage test:

≤6V  AC

4.

Current test:

AC  5~30A

5.

accuracy:

±5%

6.

Testing time:

0~99s( continuous setting )

7.

Over current alarm:

>30A  AC

8.

Alarm resistance:

 0 ~ 200mΩ   (AC  15A)  200~600mΩ   (AC  10A) ( continuous setting )

9.

accuracy:

±5%/±5%

10.

Working conditions:

(1)environment temperature 0~40ºC,(2)humidity:≤90%RH    (3)  Working power: 198~242V   47.5~52.5Hz

11.

Weight :

About 13kg
