cold room condensing unit solar air cooler DL-185
Product Description
cold room air cooler prices DL-185
| Model | cooling capacity | square meters | liquid | refrigerant diameter | fans specifications | Electric heat defrost | ||||||
| T=10C | fan capacity | qty | fan diameter | electric voltage | power | fan range | defrost power | Water power | ||||
| W | m2 | kg | mm | M3/h | mm | V | W | m | W | W | ||
| Tem: 0~20C fin = 4.5mm | ||||||||||||
| DL-2/10 | 2000 | 10 | 0.5 | 12 / 16 | 1170 | 1 | 300 | 380 | 75 | 8 | 600 | 600 |
| DL-3/15 | 3000 | 15 | 1.1 | 12 / 16 | 2340 | 2 | 300 | 380 | 2*75 | 8 | 900 | 900 |
| DL-4.3/20 | 4260 | 20 | 1.1 | 12 / 16 | 2340 | 2 | 300 | 380 | 2*75 | 8 | 900 | 900 |
| DL-5.3/25 | 5325 | 25 | 1.6 | 12 / 16 | 3510 | 2 | 300 | 380 | 2*75 | 8 | 1200 | 1200 |
| DL-8.4/40 | 8400 | 40 | 2.5 | 16 / 25 | 6800 | 2 | 400 | 380 | 2*180 | 10 | 1300 | 1300 |
| DL-12/60 | 11550 | 60 | 3.3 | 16 / 25 | 6800 | 2 | 400 | 380 | 2*180 | 10 | 1500 | 1500 |
| DL-17/80 | 16800 | 80 | 5 | 19 / 28 | 9600 | 2 | 450 | 380 | 2*250 | 12 | 3600 | 1200 |
| DL-23/105 | 23200 | 105 | 6.6 | 19 / 32 | 13140 | 2 | 500 | 380 | 2*450 | 12 | 3600 | 1200 |
| DL-28/125 | 27600 | 125 | 8.6 | 19 / 35 | 19710 | 3 | 500 | 380 | 2*450 | 12 | 4800 | 1600 |
| DL-35/160 | 34640 | 160 | 9.8 | 19 / 38 | 19710 | 3 | 500 | 380 | 2*450 | 12 | 5100 | 1700 |
| DL-40/185 | 40320 | 185 | 11.3 | 25 / 42 | 26280 | 4 | 500 | 380 | 2*450 | 12 | 6000 | 2000 |
| DL-46/210 | 46080 | 210 | 12.9 | 25 / 42 | 26280 | 4 | 500 | 380 | 2*450 | 12 | 6600 | 2200 |
| DL-52/260 | 52000 | 260 | 17.8 | 25 / 50 | 34880 | 2 | 600 | 380 | 2*1100 | 20 | 21600 | 2700 |
| DL-66/330 | 66000 | 330 | 21 | 25 / 50 | 40000 | 3 | 600 | 380 | 3*1100 | 20 | 26400 | 3300 |
| DL-82/410 | 82000 | 410 | 21.9 | 25 / 50 | 42000 | 3 | 600 | 380 | 3*1100 | 20 | 28000 | 3500 |
| DL-94/470 | 94000 | 470 | 34.9 | 25 / 54 | 42000 | 3 | 700 | 380 | 3*2200 | 20 | 20800 | 2600 |
| DL-116/580 | 11600 | 580 | 43.5 | 25 / 54 | 56000 | 4 | 700 | 380 | 4*2200 | 20 | 22400 | 2800 |
Our Services
1. For 1 year warranty
2. On line solution, recommendation.
3. With 24 hours response, and will update to give solution.
4. Engineer oversea available.
5. Promotion for the air cooler evaporator.
FAQ
More details will help us on the recommendation, and transfer our professional to you. thus help you gain more market.
1. May we know you are the distributor or the owner of one project?
2. May we know where you want to put these machines for?
3. May we know your location electric voltage?
4. If these are for the cold room projects directly, can tell us more details for your cold room?
The answers to the questions will help us on more discussion..
