PET sheet single screw plastic extruder price in SHANGHAI
- Category: >>>
- Supplier: Shanghai Yiyou Electromechanical Equipment Co. Ltd.
Share on (60579134047):
Product Overview
Description
Product Description
Our Factory manufacture PLASTIC EXTRUDER and THERMOFORMING MACHINES, MOULD/SPARE PARTS etc. And we are also providing one-stop custom thermoforming services.
| SPECIFICATIONS FOR PET SHEET EXTRUSION LINE | |
| Model | HW120/35 single screw |
| Main Motor Power | 110kw |
| Product Thickness | 0.15-2.0mm |
| Capacity | 500kg/h |
| Motor | Geman "Siemens" motor 175 HP |
| Gear box | 1 set |
| Screw diameter | Ø100 mm |
| Screw L/D ratio | 36:1 |
| Barrel temperature control | 7 zones |
| Screen changer | Hydraulic screen changer |
| Gear pump | 1 set |
| T-Die width | 8000 mm |
| Finished product width | 700 mm |
| Total weight | About 32tons |
| Occupied ground area | 18140mmX4168mmX2905mm(LXWXH) |
| SPECIFICATIONS FOR THERMOFORMING MACHINES | ||||||
Model | Forming area | Sheet’s thickness | Forming depth | Speed | Power | Weight |
HW-1000S | 610-1000(mm) | 0.2-2.0(mm) | 150(mm) | 200-400times/hour | 30kw | 1.5T |
HW-1220 | 710-1220(mm) | 0.15-2.0(mm) | 150(mm) | 220-500times/hour | 45kw | 3T |
HW-1350 | 710-1350(mm) | 0.15-2.0(mm) | 150(mm) | 220-520times/hour | 48kw | 3.2T |
More Machine Details:
Company Information
Our Advantages and Why choose us;
1). we are factory: located in No.68 of Xin Sheng Road,Qingpu Industrial Zone, Qingpu District, Shanghai,China (201713). 30minutes away from SHANGHAI HONGQIAO AIRPORT! Expressway direct to PUDONG AIRPORT!
2). our engineer has over 15 years experience about plastic and machines.
3). we have richful sources for raw material, moulds and spare parts.
4). professional shipping team in order to protect machines during loading.
5). we are also providing custom thermoforming services in case of the machine cost is out of your budget.
