Phase Change Material Microcapsule For Cooling And Heating Function

Product Overview

Description

PCM balls are manufactured with non-toxic, inorganic and organic PCM that is encapsulated in precisely engineered, high desity polyethylene(HDPE) balls for thermal energy store. HDP material remain neutral to phase change materials and transfer heat to the fluids. Once filled, the PCM ball plug is ultrasonically sealed. PCM balls are an ideal solution to design TES for off-peak energy storage and to shift on-peak demand to stabilize utility loads. The range of products allow TES designs for cold storage, ice storage, refrigeration, air conditioning, heat recovery and heat storage application.

· Material: High density Polyethylene

· Size: 20-100mm diameter

· Weight: depends on type of PCM (up to 250 g)

· Wall Thickness: 1-2mm

· Volume occupied per cubic meter: 60-70%

CHARACTERISTICS OF PCM-BALL PER CUBIC METER THERMAL ENERGY STORAGE





PCM ball	Phase Change Temperature  (°C)	Latent Heat  (kw.h/cbm)	Material of PCM	Maximum operating temperature (°C)
FJ-10	-10	26	Inorganic	50
FJ-5	-5	25	Inorganic	50
FJ5	5	27	Inorganic	50
FJ10	10	30	Inorganic	50
FJ15	15	21	Inorganic	80
FJ25	25	29	Inorganic	80
FJ35	35	33	Inorganic	80
FJ55	55	24	Inorganic	80







Applications:



· Air conditioning of office buildings, hospitals, banks, supermarkets, airports, hotels



· Process cooling in pharmaceutical industries, breweries and cold storage



· Back-up cooling in computer rooms, laboratories and chemical process industries



· Heat Recovery in power plants and process industries



· Heat Storage in solar thermal systems
