Soft yarn cone to cone winding / coning machine
- Category: >>>
- Supplier: Jiangsu Tangshi Textile Machinery Group Co. Ltd.
Share on (60586186234):
Product Overview
Description
Yarn soft cone to cone winding machine winder
TS008S Soft Cone Winding Machine
Product Description
Product Description
TS008S High Speed Soft cone winding machine——its function is to wind perfect soft cone before soft cone dyeing and it is suitable for fiber, cotton yarn, wool yarn, FDY, polyester yarn,etc.
TS008S Specification
TS008S Specification
Bobbin type | 6"(170mm) |
Power supply | 380v/220v±10% 50/60HZ |
Motor power | 90w/spindle |
Working speed | 100-1000m/min |
Take-up package | Tube Bobbin (0°) / Cone 4°20, 5°57, 9°15 |
Winding traverse | 152mm |
Max.package diameter | 250mm |
Yarn tension | Every spindle with disc tensioner |
Driving | Every spindle per motor |
Auto stop device | Each spindle has yarn detector |
Length counter | Each spindle has length counter |
Electronic yarn clearer | Optional installed |
Air splicer | Optional installed |
Blower cleaner | Optional installed |
Lighting system | Contain |
Dimensions | L11650 x W 1150 x H 1600 mm (60 spindles) |
Main Features
Main Features
1. Winding speed is 100-1000meter/min,which can be adjusted according to your yarn. Cotton: about 800M/min, Fiber : about 600 M/min,etc. (Density: 0.2-0.4g/cm³)
2.The winding speed and length of all the spindles can be set the same and shown on the touch screen. Also,each spindle is individual and has length counter. Winding speed and take-up length of each spindle can be set differently and shown on each control panel.
3.Each spindle has systems of Anti-Hard-Edge and Electronic Anti-overlapping.
4.Each spindle has auto-stop device(motion sensor/yarn detector).When the yarn broken or the yarn cone finished,the motor of the spindle will immediately stop.
Packaging & Shipping
Packaging&Shipping
Before loading,the machines are covered with waterproof plastic first,then packed in solid wooden case.
Company Information
Jiangsu Tangshi Textile Machinery Group Co., Ltd was an experienced and professional manufacturer, it already has 30 years' experience of producing drum winding machines, with advanced technics and production equipments it can output more one thousand winding machines annually. after these years hard work and faith cooperation, Jiangsu Tangshi Textile Group Co., Ltd got a good reputation. our products like GA014 series soft and tight winding machine, TS008 semi-automatic soft and tight winding machine, TS230,280,290,300 big take-up winding machine. and we also can customize machines according to the customers' special demands. we service the textile industry in conformance with the aim of “professional produce, faith operation, reputation brand ”. The products are widely sold at domestic and also export to south-east asia countries gradually.To supply all kinds of winding machine is our company's feature, good quality and in time deliverly is our promise. sincerely hope we can go forward hand in hand and set up bright life together!Winding machine------------Jiangsu Tangshi Textile Machienry Group Co., Ltd will be your best choose!
