Mini Wheat Diesel engine Wheat and Rice Reaper Binder/Good quality automatic reaper binder
- Category: >>>
- Supplier: Zhejiang Ting Neng Sheng Machine Co. Ltd.
Share on (60586325164):
Product Overview
Description
| Model:TNS-GK-140-3 WHEELS REAPER BINDER | |
| DATA | |
| Overall dimensions | 3600*1950*1200mm |
| Cutting width | 140cm |
| Demanded plant height | <=1.8m |
| Stem diameter | Max:4cm General:2cm(one spring can be adjusted) |
| Ground clearance | 8-10cm(2-3cm once the protector block removed) |
| Weight | 400KG |
| Working capacity | 1 acre/hr |
| Engine type | Single-cylinder,vertical,4-storke,air-cooled,direct-injection diesel. |
| Displacement | 456cc |
| Fule consumption(g/kw.h) | 280 |
| Horse power | 12(8.8kw) |
| Compression radio | 22:1 |
| Starting system | Electric |
| Fuel tank capacity(L) | 5.5 |
| Lub.Oil capacity(L) | 1.65 |
| Continuous working time(h) | 5.5 |
| Oil consumption | 1L/h |
| Cooling system | Forced air |
| Loading Quantity | 20FCL:6pcs / 40HQ:21pcs |
THE PACKING SHOW
Other FAQ Parts
1. Q: How about your after-sale system?
A:Our company provides perfect after-sale service, if there is any problem that you can not solve by yourself, please contact with our salesman, and they will try to help you together with our engineers.
2. Q: How to order spare parts? Is that available?
A:For each TNS-GK-140 reaper binder, there is one tool bag, inside it there are three copies of catalogue, one of them is spare parts catalogue, if you want to order some spare parts, please refer to it. If you can not match the real parts to the reference number, please contact with our salesman, they will help you. All of those spare parts are available. It is easy to purchase from us.
3.Q: How to decide packing? A:There are altogether three kinds of ways for the packing. Our salesman will illustrate them for you so that you can chose the suitable one according to your real situation. Both wooden case and carton box is good for packing. If you want to do the outside marks, please inform our salesman in advance, and leave them enough time to do the preparation.
4.Q: About orders
A:Generally there are two seasons in the whole year, are March to April and September to October. But different areas still depend. Anyway, if you are interested in our machine, please try to contact with our salesman in advance so that there is enough time for manufacturing.
5.PS: If there is something unclear for you, please feel ease to contact with us, all the staff are convenient for you.
This information will be updated from time to time, so please contract with us. Our company reserves the final rights to explain anything that is unclear.
Best wishes and regards! View More
